TI SN65DSI83ZQER
TI SN65DSI83ZQER

TI SN65DSI83ZQER

Manufacturer No:

SN65DSI83ZQER

Manufacturer:

TI

Package:

64-VFBGA

Description:

Copper, Silver, Tin Specialized Interface IC FlatLink? Series 65DSI83 64 Pin 1.8V 64-VFBGA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SN65DSI83ZQER information

TI SN65DSI83ZQER technical specifications, attributes, parameters and parts with similar specifications to TI SN65DSI83ZQER.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 6 days ago)
  • Factory Lead Time
  • 6 Weeks
  • Contact Plating
  • Copper, Silver, Tin
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 64-VFBGA
  • Number of Pins
  • 64
  • Packaging
  • Tape & Reel (TR)
  • Series
  • FlatLink?
  • JESD-609 Code
  • e1
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 64
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin/Silver/Copper (Sn/Ag/Cu)
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Applications
  • Notebook Computer
  • Voltage - Supply
  • 1.65V~1.95V
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Base Part Number
  • 65DSI83
  • Temperature Grade
  • INDUSTRIAL
  • Interface
  • Serial
  • Nominal Supply Current
  • 112mA
  • Max Output Voltage
  • 511mV
  • Data Rate
  • 1 Gbps
  • Max Input Current
  • 30?A
  • Telecom IC Type
  • TELECOM CIRCUIT
  • Number of Drivers
  • 4
  • Height
  • 1mm
  • Length
  • 5mm
  • Width
  • 5mm
  • Thickness
  • 740?m
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for TI SN65DSI83ZQER.

PCN Design/Specification:

SN65DSI83ZQERDescription


The SN65DSI83ZQER is a Single-channel MIPI® DSI to single-link LVDS bridge & Flatlink? integrated circuit.



SN65DSI83ZQER Features


  • Implements MIPI® D-PHY version 1.00.00 physical layer front-end and display serial interface (DSI) version 1.02.00

  • Single channel DSI receiver configurable for 1, 2, 3, or 4 D-PHY data lanes per channel operating up to 1 Gbps/lane

  • Supports 18 bpp and 24 bpp DSI video packets with RGB666 and RGB888 formats

  • FlatLink? output for single-link LVDS

  • Supports single-channel DSI to single-link LVDS operating mode

  • LVDS Output Clock Range of 25 MHz to 154 MHz

  • LVDS pixel clock may be sourced from a freerunning continuous D-PHY clock or external reference clock (REFCLK)

  • 1.8-V main VCC power supply

  • Low power features include shutdown mode, reduced LVDS output voltage swing, common mode, and MIPI ultra-low power state (ULPS) support

  • LVDS channel swap, LVDS PIN order reverse feature for ease of PCB routing

  • ESD rating ±2 kV (HBM)

  • Packaged in 64-pin 5-mm × 5-mm nFBGA (ZXH)

  • Temperature range: ?40°C to 85°C



SN65DSI83ZQER Applications



  • PC & notebooks

  • Tablets

  • Connected peripherals & printers


User Guide
