SAMTEC SMA-J-P-H-ST-EM1

Manufacturer No:

SMA-J-P-H-ST-EM1

Manufacturer:

SAMTEC

Package:

Description:

Jack, Female Socket Threaded 50Ohm Tray SMA Solder 1 Port Polytetrafluoroethylene (PTFE) -65°C~125°C

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SMA-J-P-H-ST-EM1 information

SAMTEC SMA-J-P-H-ST-EM1 technical specifications, attributes, parameters and parts with similar specifications to SAMTEC SMA-J-P-H-ST-EM1.

Type
Parameter

Factory Lead Time
5 Weeks

Contact Material
Copper

Mount
Edge

Mounting Type
Board Edge, End Launch

Insulation Material
Polytetrafluoroethylene

Dielectric Material
Polytetrafluoroethylene (PTFE)

Body Material
Brass

Center Contact Plating
Gold

Center Contact Material
Beryllium Copper

Operating Temperature
-65°C~125°C

Packaging
Tray

Published
2009

JESD-609 Code
e4

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Connector Type
Jack, Female Socket

Voltage - Rated
335V

Fastening Type
Threaded

MIL Conformance
NO

DIN Conformance
NO

IEC Conformance
NO

Filter Feature
NO

Option
GENERAL PURPOSE

Total Number of Contacts
1

Depth
13.33mm

Frequency
20GHz

Reliability
COMMERCIAL

Mating Information
MULTIPLE MATING PARTS AVAILABLE

Contact Style
COAX

Contact Resistance
60mOhm

Insulation Resistance
5000000000Ohm

Termination Type
SURFACE MOUNT

Impedance
50Ohm

Connector Style
SMA

Number of Ports
1

Contact Termination
Solder

Length
6.35mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for SAMTEC SMA-J-P-H-ST-EM1.

SMA-J-P-H-ST-EM1 Overview

The connector type Jack, Female Socket refers to the connector type.The device's mounting type is Board Edge, End Launch.In order to package the product, a Tray case is used.It features 1 ports for managing a variety of tasks.The part is mounted by Edge.The device runs in -65°C~125°C Operating Temperature.Its frequency is 20GHz.
