Manufacturer No:

SMA-J-P-H-RA-TH1

Manufacturer:

SAMTEC

Package:

Description:

Jack, Female Socket Threaded 50Ohm Tube SMA Solder 1 Port Polytetrafluoroethylene (PTFE) -65°C~125°C

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SMA-J-P-H-RA-TH1 information

SAMTEC SMA-J-P-H-RA-TH1 technical specifications, attributes, parameters and parts with similar specifications to SAMTEC SMA-J-P-H-RA-TH1.

  • Type
  • Parameter
  • Factory Lead Time
  • 3 Weeks
  • Mount
  • Bulkhead, Panel, Through Hole
  • Mounting Type
  • Through Hole, Right Angle
  • Insulation Material
  • Polytetrafluoroethylene
  • Dielectric Material
  • Polytetrafluoroethylene (PTFE)
  • Body Material
  • Brass
  • Center Contact Plating
  • Gold
  • Center Contact Material
  • Beryllium Copper
  • Manufacturer Package Identifier
  • SMA-J-P-H-RA-TH1
  • Operating Temperature
  • -65°C~125°C
  • Packaging
  • Tube
  • Published
  • 2012
  • JESD-609 Code
  • e4
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Connector Type
  • Jack, Female Socket
  • Voltage - Rated
  • 335V
  • Fastening Type
  • Threaded
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • IEC Conformance
  • NO
  • Filter Feature
  • NO
  • Option
  • GENERAL PURPOSE
  • Total Number of Contacts
  • 1
  • Depth
  • 7mm
  • Frequency
  • 20GHz
  • Reliability
  • COMMERCIAL
  • Mating Information
  • MULTIPLE MATING PARTS AVAILABLE
  • Contact Style
  • COAX
  • Contact Resistance
  • 60mOhm
  • Insulation Resistance
  • 5000000000Ohm
  • Impedance
  • 50Ohm
  • Connector Style
  • SMA
  • Number of Ports
  • 1
  • Contact Termination
  • Solder
  • Insertion Loss
  • 0.3 dB
  • Height
  • 10.12mm
  • Length
  • 15.1mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for SAMTEC SMA-J-P-H-RA-TH1.

Datasheets:

SMA-J-P-H-RA-TH1 Overview


The connector type Jack, Female Socket refers to the connector type.The device's mounting type is Through Hole, Right Angle.In order to package the product, a Tube case is used.It features 1 ports for managing a variety of tasks.The part is mounted by Bulkhead, Panel, Through Hole.The device runs in -65°C~125°C Operating Temperature.Its frequency is 20GHz.
