Manufacturer No:

SKY13290-313LF

Manufacturer:

SKYWORKS

Package:

6-VDFN Exposed Pad

Description:

General Purpose RF Type SPDT -40°C~85°C 20MHz~2.5GHz Isolation:18dB Insertion Loss:0.55dB Reflective 50Ohm

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SKY13290-313LF information

SKYWORKS SKY13290-313LF technical specifications, attributes, parameters and parts with similar specifications to SKYWORKS SKY13290-313LF.

  • Type
  • Parameter
  • Factory Lead Time
  • 12 Weeks
  • Contact Plating
  • Tin
  • Mount
  • Surface Mount
  • Package / Case
  • 6-VDFN Exposed Pad
  • Number of Pins
  • 6
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2012
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 20
  • Termination
  • SMD/SMT
  • ECCN Code
  • EAR99
  • Additional Feature
  • HIGH ISOLATION
  • HTS Code
  • 8542.39.00.01
  • Subcategory
  • RF/Microwave Switches
  • Number of Functions
  • 1
  • Construction
  • COMPONENT
  • Frequency
  • 2.5GHz
  • Circuit
  • SPDT
  • Power Supplies
  • 5V
  • Max Supply Voltage
  • 10V
  • Impedance
  • 50Ohm
  • Turn On Delay Time
  • 800 ns
  • Topology
  • Reflective
  • Turn-Off Delay Time
  • 800 ns
  • Frequency Range
  • 20MHz~2.5GHz
  • Insertion Loss
  • 0.55dB
  • Isolation
  • 18dB
  • Insertion Loss (dB)
  • 0.55 dB
  • RF Type
  • General Purpose
  • Input Power-Max (CW)
  • 43.5dBm
  • 1dB Compression Point
  • 15 dBm
  • Height
  • 1.05mm
  • REACH SVHC
  • Unknown
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for SKYWORKS SKY13290-313LF.

Datasheets:

PCN Assembly/Origin:

SKY13290-313LF Overview


Using the Tape & Reel (TR) package, this RF Switch optimizes the performance of the RF Switch 12v.A RF Switch consists of 20 terminations.In order for it to operate properly, RF Switch's operating temperature should be at -40°C~85°C.There is a subcategory of this RF light switch called RF/Microwave Switches.In order to operate high power RF switch, 6 pins are required.This RF switch ic is more efficient and stable due to its HIGH ISOLATION feature.An RF switch ic with the General Purpose RF type.

SKY13290-313LF Features


Tape & Reel (TR) package
20 terminations
RF/Microwave Switches subcategory
6 pins
HIGH ISOLATION
General Purpose RF Type


SKY13290-313LF Applications


There are a lot of Skyworks Solutions Inc.
SKY13290-313LF RF Switches applications.


  • Tuner modules
  • Antenna diversity switching
  • Cellular/PCS Base Stations
  • ISM
  • Wireless Local Loop
  • Smartphones
  • Tablets
  • Mobile devices
  • Smart metering
  • Cellular infrastructures
