ONSEMI SG3525ANG
ONSEMI SG3525ANG

ONSEMI SG3525ANG

Manufacturer No:

SG3525ANG

Manufacturer:

ONSEMI

Package:

16-DIP (0.300, 7.62mm)

Description:

PWM Controller

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SG3525ANG information

ONSEMI SG3525ANG technical specifications, attributes, parameters and parts with similar specifications to ONSEMI SG3525ANG.

  • Type
  • Parameter
  • Package Type
  • PDIP-16
  • MSL Type
  • NA
  • Topology
  • Flyback
  • Phases
  • 1
  • Control Mode
  • Voltage Mode
  • VCC Max (V)
  • 35
  • Case Outline
  • 648-08
  • MSL Temp (°C)
  • 0
  • Container Type
  • TUBE
  • Container Qty.
  • 25
  • VCC Min (V)
  • 8
  • fSW Typ (kHz)
  • 100-400

Download datasheets and manufacturer documentation for ONSEMI SG3525ANG.

Datasheet:

Package Drawing:

The SG3525A PWM Controller offers improved performance and lower external parts count when implemented for controlling all types of switching power supplies. The on-chip +5.1 V reference is trimmed to +/-1% and the error amplifier has an input common-mode voltage range that includes the reference voltage, thus eliminating the need for external divider resistors. A sync input to the oscillator enables multiple units to be slaved or a single unit to be synchronized to an external system clock. A wide range of deadtime can be programmed by a single resistor connected between the CT and Discharge pins. This device also features built-in soft-start circuitry, requiring only an external timing capacitor. A shutdown pin controls both the soft-start circuitry and the output stages, providing instantaneous turn off through the PWM latch with pulsed shutdown, as well as soft-start recycle with longer shutdown commands. The under voltage lockout inhibits the outputs and the changing of the soft-start capacitor when VCC is below nominal. The output stages are totem-pole design capable of sinking and sourcing in excess of 200 mA. The output stage of the SG3525A features NOR logic resulting in a low output for an off-state.

Application

  • Half Bridge
  • Push-Pull

Feature

  • 8.0 V to 35 V Operation
  • 5.1 V +/- 1.0% Trimmed Reference
  • 100 Hz to 400 kHz Oscillator Range
  • Separate Oscillator Sync Pin
  • Adjustable Deadtime Control
  • Input Undervoltage Lockout
  • Latching PWM to Prevent Multiple Pulses
  • Pulse-by-Pulse Shutdown
  • Dual Source/Sink Outputs: +/- 400 mA Peak
  • Pb-Free Packages are Available*
