Manufacturer No:

SEAF8-20-05.0-S-06-2-K

Manufacturer:

SAMTEC

Package:

Description:

High Density Array, Female Tape & Reel (TR) 6 Rows 0.031 0.80mm Surface Mount 120 Positions SEARAY™ SEAF Gold Solder COPPER ALLOY

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SEAF8-20-05.0-S-06-2-K information

SAMTEC SEAF8-20-05.0-S-06-2-K technical specifications, attributes, parameters and parts with similar specifications to SAMTEC SEAF8-20-05.0-S-06-2-K.

  • Type
  • Parameter
  • Factory Lead Time
  • 3 Weeks
  • Contact Material
  • COPPER ALLOY
  • Mounting Type
  • Surface Mount
  • Insulation Material
  • LIQUID CRYSTAL POLYMER (LCP)
  • Mounting Option 1
  • LOCKING
  • Board Mounting Option
  • PEG
  • Packaging
  • Tape & Reel (TR)
  • Series
  • SEARAY™ SEAF
  • JESD-609 Code
  • e3
  • Feature
  • Board Guide, Pick and Place
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • High Density Array, Female
  • Number of Positions
  • 120
  • Number of Rows
  • 6
  • Gender
  • Female
  • Subcategory
  • Headers and Edge Type Connectors
  • Pitch
  • 0.031 0.80mm
  • Total Number of Contacts
  • 120
  • Number of Conductors
  • ONE
  • Contact Finish
  • Gold
  • Reliability
  • COMMERCIAL
  • PCB Contact Pattern
  • RECTANGULAR
  • Operating Temperature (Max)
  • 125°C
  • Body Breadth
  • 0.307 inch
  • Operating Temperature (Min)
  • -55°C
  • Body Depth
  • 0.179 inch
  • Rated Current (Signal)
  • 1.4A
  • Contact Style
  • BELLOWED TYPE
  • Polarization Key
  • POLARIZED HOUSING
  • Contact Pattern
  • RECTANGULAR
  • Insulator Color
  • BLACK
  • Contact Finish Thickness
  • 30.0μin 0.76μm
  • Plating Thickness
  • 30μin
  • Height Above Board
  • 0.180 4.57mm
  • Stack Height (Mating)
  • 7mm 10mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for SAMTEC SEAF8-20-05.0-S-06-2-K.

SEAF8-20-05.0-S-06-2-K Overview


A High Density Array, Female package is included with it.Packaging is performed using a Tape & Reel (TR) case.Its mounting type is Surface Mount.It is part of the SEARAY™ SEAF Series of products.In operation, Board Guide, Pick and Place may be maintained.

SEAF8-20-05.0-S-06-2-K Features


SEARAY™ SEAF series
Package / Case: Tape & Reel (TR)
Mounting Type:Surface Mount


SEAF8-20-05.0-S-06-2-K Applications


There are a lot of Samtec Inc.
SEAF8-20-05.0-S-06-2-K Rectangular Connectors applications.


  • Embedded systems
  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
