Manufacturer No:

SE2547A-R

Manufacturer:

SKYWORKS

Package:

32-TFLGA Exposed Pad

Description:

Surface Mount 32-TFLGA Exposed Pad Digi-Reel® Front End 2.4GHz~2.5GHz 4.9GHz~5.875GHz 802.11a/b/g/n 32 Terminations 5mm

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SE2547A-R information

SKYWORKS SE2547A-R technical specifications, attributes, parameters and parts with similar specifications to SKYWORKS SE2547A-R.

  • Type
  • Parameter
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 32-TFLGA Exposed Pad
  • Surface Mount
  • YES
  • Weight
  • 50.008559mg
  • Packaging
  • Digi-Reel®
  • Series
  • SiGe
  • Published
  • 2012
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 32
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • 0°C
  • HTS Code
  • 8542.39.00.01
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BUTT
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.5mm
  • Reach Compliance Code
  • unknown
  • Frequency
  • 2.4GHz~2.5GHz 4.9GHz~5.875GHz
  • JESD-30 Code
  • S-PBGA-B32
  • Function
  • Front End
  • Operating Supply Voltage
  • 3.3V
  • Temperature Grade
  • OTHER
  • Operating Supply Current
  • 250mA
  • Telecom IC Type
  • TELECOM CIRCUIT
  • RF Type
  • 802.11a/b/g/n
  • Length
  • 5mm
  • Height Seated (Max)
  • 1.1mm
  • Width
  • 5mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for SKYWORKS SE2547A-R.

Datasheets:

SE2547A-R Overview


On the basis of the frequency 2.4GHz~2.5GHz 4.9GHz~5.875GHz, RF modulator operates.An excellent RF IC thanks to its enhanced 32-TFLGA Exposed Pad package.The Digi-Reel® package houses this RF modulator.A Surface Mount-type PCB or development board can be used to place this RF modulator.This RF module has 32 terminations for driving and receiving data signals.During operation, the RF switch IC's temperature must be below 85°C.It is important that this RF switch IC does not operate at 0°C degrees Celsius at its minimum operating temperature.Optimal performance can be achieved by operating the RF modulator's supply current in the 250mA range.

SE2547A-R Features


Frequency of 2.4GHz~2.5GHz 4.9GHz~5.875GHz
32-TFLGA Exposed Pad package
Digi-Reel®
32 terminations


SE2547A-R Applications


There are a lot of Skyworks Solutions Inc.
SE2547A-R RF Misc ICs and Modules applications.


  • Communications test equipmen
  • PA linearization
  • PA predistortion
  • Amplitude modulation
  • Phase modulation
  • Variable matched attenuator
  • Phase shifter
  • Cellular base stations
  • Radio links
  • Fixed wireless access
