Semtech SD12C.TCT
Semtech SD12C.TCT

Semtech SD12C.TCT

Manufacturer No:

SD12C.TCT

Manufacturer:

Semtech

Package:

SC-76, SOD-323

Description:

ESD Suppressor TVS 30KV 2-Pin SOD-323 T/R

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

SD12C.TCT information

Semtech SD12C.TCT technical specifications, attributes, parameters and parts with similar specifications to Semtech SD12C.TCT.

  • Type
  • Parameter
  • Factory Lead Time
  • 6 Weeks
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • SC-76, SOD-323
  • Number of Pins
  • 2
  • Diode Element Material
  • SILICON
  • Number of Elements
  • 1
  • Reverse Stand-off Voltage
  • 12V
  • Operating Temperature
  • -55°C~125°C TJ
  • Packaging
  • Tape & Reel (TR)
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • ECCN Code
  • EAR99
  • Type
  • Zener
  • Terminal Finish
  • Matte Tin (Sn)
  • Applications
  • General Purpose
  • Additional Feature
  • TRANSIENT PROTECTION
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Depth
  • 1.4mm
  • Pin Count
  • 2
  • Working Voltage
  • 12V
  • Polarity
  • Bidirectional
  • Leakage Current
  • 1μA
  • Element Configuration
  • Single
  • Power Dissipation
  • 350W
  • Power Line Protection
  • No
  • Current - Peak Pulse (10/1000μs)
  • 15A 8/20μs
  • Clamping Voltage
  • 24V
  • Voltage - Reverse Standoff (Typ)
  • 12V Max
  • Peak Pulse Current
  • 15A
  • Peak Pulse Power
  • 350W
  • Direction
  • Bidirectional
  • Test Current
  • 1mA
  • Capacitance @ Frequency
  • 100pF @ 1MHz
  • Reverse Breakdown Voltage
  • 13.3V
  • Length
  • 1.8mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for Semtech SD12C.TCT.

PCN Packaging:

Datasheets:

Product Description:

The SD12C.TCT is a surface-mount transient voltage suppressor (TVS) diode from Semtech Corporation, designed for general-purpose applications. This bidirectional TVS diode features a clamping voltage of 24V and a peak pulse current of 15A, making it suitable for protecting electronic devices from voltage spikes and surges.

Features:

  • Transient Protection: The SD12C.TCT provides transient voltage protection, ensuring the safe operation of electronic devices in the presence of voltage spikes and surges.
  • High Current Capability: With a peak pulse current of 15A, this TVS diode can handle high current surges, making it suitable for applications requiring robust protection.
  • Wide Operating Temperature Range: The diode operates within a temperature range of -55°C to 125°C, ensuring reliable performance in various environmental conditions.
  • Lead-Free and RoHS Compliant: The SD12C.TCT is manufactured using lead-free materials and is compliant with the Restriction of Hazardous Substances (RoHS) directive.

Applications:

  • Primary Applications: General-purpose applications, such as power supplies, motor drives, and industrial control systems.
  • Secondary Applications: Audio equipment, medical devices, and automotive systems.

Alternative Parts:

  • SD12: The base part number of the SD12C.TCT, which can be used as an alternative in applications requiring similar specifications.

Embedded Modules:

  • Various Power Supplies: The SD12C.TCT is used in various power supply designs to provide transient voltage protection.
  • Industrial Control Systems: This TVS diode is used in industrial control systems to protect against voltage spikes and surges.

FAQs:

Q: What is the clamping voltage of the SD12C.TCT? A: The clamping voltage of the SD12C.TCT is 24V.

Q: What is the peak pulse current of the SD12C.TCT? A: The peak pulse current of the SD12C.TCT is 15A.

Q: What is the operating temperature range of the SD12C.TCT? A: The operating temperature range of the SD12C.TCT is -55°C to 125°C.

Q: Is the SD12C.TCT lead-free and RoHS compliant? A: Yes, the SD12C.TCT is manufactured using lead-free materials and is compliant with the RoHS directive.

Q: What is the packaging of the SD12C.TCT? A: The SD12C.TCT is packaged in a tape and reel (TR) format.

Q: What is the moisture sensitivity level (MSL) of the SD12C.TCT? A: The MSL of the SD12C.TCT is 1 (unlimited), indicating that it can be stored in an unlimited environment without the need for special storage conditions.
