SCG2500-77.76M Information

Connor-Winfield SCG2500-77.76M technical specifications, attributes, parameters and parts with similar specifications to Connor-Winfield SCG2500-77.76M.

Type
Parameter

Factory Lead Time
12 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
14-SMD Module

Operating Temperature
0°C~70°C

Packaging
Tube

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
14

Type
Clock Generator

Type
Parameter

Technology
HYBRID

Voltage - Supply
3.135V~3.465V

Terminal Position
DUAL

Terminal Form
J BEND

Supply Voltage
3.3V

Terminal Pitch
2.54mm

Frequency
77.8MHz

Output
CMOS

Qualification Status
Not Qualified

Power Supplies
3.3V

Download datasheets and manufacturer documentation for Connor-Winfield SCG2500-77.76M.

SCG2500-77.76M Overview

As a clock IC, PLLs is packaged using the Tube method. This clock generator is embedded in the 14-SMD Module package. 14 terminations can be found in frequency synthesizer. Basically, a voltage of 3.3V should be applied to this electronic frequency generator. Clock is designed as this clock generator's input. 1 circuits are implemented to access the electronic component's full performance. This clock-based frequency generator provides a frequency up to 77.76MHz Max. This component can be conveniently installed on the panel thanks to the Surface Mount. Clock PLL works with 3.135V~3.465V supply voltage provided. The ambient temperature should be set at 0°C~70°C, which is estimated by the test statistics. This is a clock generator compatible with CMOS logic levels. This electronic component can be classified as a Clock Generator. Frequency generator is able to reali77.8MHze high efficiency when operating at a frequency of 77.8MHz.

SCG2500-77.76M Features

Available in the 14-SMD Module
Supply voltage of 3.3V

SCG2500-77.76M Applications

There are a lot of Connor-Winfield
SCG2500-77.76M Clock Generators applications.

Instrument
Automatic test equipment
Wide area power system
Digital circuits
Wireless base station for LTE, LTE-advanced
Picocells, femtocells and small cells
Sampling clocks for ADC and DAC
1 Gigabit Ethernet
10 Gigabit Ethernet
FPGA and processor clocks
