NXP S9S12ZVLS3F0MFMR

Manufacturer No:

S9S12ZVLS3F0MFMR

Manufacturer:

NXP

Package:

32-VFQFN Exposed Pad

Description:

32KB 32K x 8 FLASH S12Z 16-Bit Microcontroller S12 MagniV Series 5V 32-VFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

S9S12ZVLS3F0MFMR information

NXP S9S12ZVLS3F0MFMR technical specifications, attributes, parameters and parts with similar specifications to NXP S9S12ZVLS3F0MFMR.

Type
Parameter

Factory Lead Time
12 Weeks

Mounting Type
Surface Mount

Package / Case
32-VFQFN Exposed Pad

Surface Mount
YES

Operating Temperature
-40°C~125°C TA

Packaging
Tape & Reel (TR)

Series
S12 MagniV

Published
2013

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
32

ECCN Code
3A991.A.2

HTS Code
8542.31.00.01

Technology
CMOS

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Supply Voltage
5V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
40

JESD-30 Code
S-XQCC-N32

Supply Voltage-Max (Vsup)
18V

Supply Voltage-Min (Vsup)
5.5V

Oscillator Type
Internal

Speed
32MHz

RAM Size
1K x 8

Voltage - Supply (Vcc/Vdd)
5.5V~18V

uPs/uCs/Peripheral ICs Type
MICROCONTROLLER

Core Processor
S12Z

Peripherals
LVD, POR, PWM, WDT

Clock Frequency
25MHz

Program Memory Type
FLASH

Core Size
16-Bit

Program Memory Size
32KB 32K x 8

Connectivity
I2C, IrDA, LINbus, SCI, SPI, UART/USART

Bit Size
16

Data Converter
A/D 6x10b

Has ADC
NO

DMA Channels
NO

PWM Channels
NO

DAC Channels
NO

ROM (words)
32768

EEPROM Size
128 x 8

On Chip Program ROM Width
8

Length
5mm

Height Seated (Max)
0.9mm

Width
5mm
