INTEL S80C188XL20

Manufacturer No:

S80C188XL20

Manufacturer:

INTEL

Package:

PQFP

Description:

0.8mm 5V 16-bit Microprocessor 80-Pin 20MHz 5V PQFP

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

S80C188XL20 information

INTEL S80C188XL20 technical specifications, attributes, parameters and parts with similar specifications to INTEL S80C188XL20.

Type
Parameter

Mount
Surface Mount

Package / Case
PQFP

Number of Pins
80

Packaging
Bulk

JESD-609 Code
e0

Number of Terminations
80

ECCN Code
3A991.A.2

Terminal Finish
Tin/Lead (Sn/Pb)

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Additional Feature
DRAM REFRESH CONTROLLER; 3 PROGRAMMABLE TIMERS

HTS Code
8542.31.00.01

Subcategory
Microprocessors

Technology
CMOS

Terminal Position
QUAD

Terminal Form
GULL WING

Supply Voltage
5V

Terminal Pitch
0.8mm

Frequency
20MHz

Pin Count
80

Qualification Status
Not Qualified

Operating Supply Voltage
5V

Power Supplies
5V

Temperature Grade
COMMERCIAL

Max Supply Voltage
5.5V

Min Supply Voltage
4.5V

uPs/uCs/Peripheral ICs Type
MICROPROCESSOR

Supply Current-Max
90mA

Bit Size
16

Address Bus Width
20

Boundary Scan
NO

Low Power Mode
YES

External Data Bus Width
8

Format
FIXED POINT

Integrated Cache
NO

RAM (words)
0

Number of External Interrupts
5

Number of DMA Channels
2

Length
20mm

Height Seated (Max)
3.15mm

Width
14mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for INTEL S80C188XL20.

ConflictMineralStatement:

intel-cnla6000pk5-conflictmineralstatement-0045.pdf

S80C188XL20 Overview

With a packing size of PQFP, this embedded microprocessor is ideal for international shipping. High reliability is achieved with advanced packaging method Bulk. I would rate this as a MICROPROCESSOR for the uPs/uCs/Peripheral ICs type. As a whole, there are 80 terminations. A 5V voltage supply should be used to turn on and run the cpu microprocessor. There is a 16-Bit architecture in it. At 20MHz, the CPU operates. For information about 80 pins, please refer to the datasheet. As a typical Microprocessors, this cpu microprocessor has Microprocessors display. With a 8 external data bus width, this CPU has a wide data bus. CPU microprocessors shouldn't be used in environments above 70°C. There are 80 pins injected into the embedded microprocessor body. With the Surface Mount mounted, this CPU is widely used in a wide range of applications. As of 5V, the CPU microprocessor is capable of functioning. The micro processor requires 5V power supplies according to the datasheets. A CPU core voltage of 5V is present. Voltage can't exceed 90mA to the CPU. Microprocessors should never be supplied with voltages above 5.5V in normalcircumstances. Micro processors should be supplied with 4.5V as their lowest voltage. Be sure not to miss the following additional features of this microprocessor: DRAM REFRESH CONTROLLER; 3 PROGRAMMABLE TIMERS. For hardware interrupts, there are 5 external interrupt terminations. The DMA (Direct Memory Access) process is programmed using 2 channels.
