RICHTEK RT7276GCP
Manufacturer No:
RT7276GCP
Manufacturer:
Package:
14-TSSOP (0.173, 4.40mm Width) Exposed Pad
Description:
4.5V 14-Pin DC DC Voltage Regulator SWITCHING REGULATOR 1 Outputs 700kHz Tape & Reel (TR) 3A 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
RT7276GCP information
RICHTEK RT7276GCP technical specifications, attributes, parameters and parts with similar specifications to RICHTEK RT7276GCP.
- Type
- Parameter
- Factory Lead Time
- 16 Weeks
- Mount
- Surface Mount
- Mounting Type
- Surface Mount
- Package / Case
- 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
- Number of Pins
- 14
- Operating Temperature
- -40°C~85°C TA
- Packaging
- Tape & Reel (TR)
- Series
- ACOT™
- Published
- 2013
- Pbfree Code
- yes
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 3 (168 Hours)
- ECCN Code
- EAR99
- Peak Reflow Temperature (Cel)
- NOT SPECIFIED
- Time@Peak Reflow Temperature-Max (s)
- NOT SPECIFIED
- Function
- Step-Down
- Number of Outputs
- 1
- Voltage - Input (Max)
- 18V
- Output Voltage
- 8V
- Output Type
- Adjustable
- Voltage - Input (Min)
- 4.5V
- Analog IC - Other Type
- SWITCHING REGULATOR
- Output Configuration
- Positive
- Current - Output
- 3A
- Voltage - Output (Min/Fixed)
- 0.765V
- Topology
- Buck
- Frequency - Switching
- 700kHz
- Synchronous Rectifier
- Yes
- Min Output Voltage
- 765mV
- REACH SVHC
- Unknown
- RoHS Status
- RoHS Compliant
