Qorvo RF2052TR13
Manufacturer No:
RF2052TR13
Manufacturer:
Package:
32-VFQFN Exposed Pad
Description:
Cellular 30MHz~2.5GHz 1-Mixer 12dB Up/Down Converter -40°C-Min 85°C-Max Matte Tin (Sn) - annealed 32-VFQFN Exposed Pad
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
RF2052TR13 information
Qorvo RF2052TR13 technical specifications, attributes, parameters and parts with similar specifications to Qorvo RF2052TR13.
- Type
- Parameter
- Mounting Type
- Surface Mount
- Package / Case
- 32-VFQFN Exposed Pad
- Surface Mount
- YES
- Packaging
- Tape & Reel (TR)
- JESD-609 Code
- e3
- Pbfree Code
- yes
- Part Status
- Discontinued
- Moisture Sensitivity Level (MSL)
- 2 (1 Year)
- Number of Terminations
- 32
- ECCN Code
- EAR99
- Terminal Finish
- Matte Tin (Sn) - annealed
- Subcategory
- Other Telecom ICs
- Technology
- CMOS
- Voltage - Supply
- 2.7V~3.6V
- Terminal Position
- QUAD
- Terminal Form
- NO LEAD
- Peak Reflow Temperature (Cel)
- 260
- Number of Functions
- 1
- Supply Voltage
- 3V
- Terminal Pitch
- 0.5mm
- Frequency
- 30MHz~2.5GHz
- Time@Peak Reflow Temperature-Max (s)
- 30
- Pin Count
- 32
- JESD-30 Code
- S-PQCC-N32
- Operating Temperature (Max)
- 85°C
- Operating Temperature (Min)
- -40°C
- Power Supplies
- 3V
- Temperature Grade
- INDUSTRIAL
- Operating Supply Current
- 75mA
- Gain
- -2dB
- Telecom IC Type
- TELECOM CIRCUIT
- RF Type
- Cellular
- Secondary Attributes
- Up/Down Converter
- Noise Figure
- 12dB
- Number of Mixers
- 1
- Length
- 5mm
- Width
- 5mm
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for Qorvo RF2052TR13.
Datasheets:
RF2052TR13 Overview
A high level of reliability is provided by using an advanced RF mixer' packaging Tape & Reel (TR).The mixer RF ships overseas conveniently packed in 32-VFQFN Exposed Pad.This RF circuit board needs to operate at 75mA supply current in order to deliver its performance.The RF mixer has type Cellular RF.The mount is provided by Surface Mount.
RF2052TR13 Features
Packed in 32-VFQFN Exposed Pad
75mAmA
Cellular Type
RF2052TR13 Applications
There are a lot of RFMD
RF2052TR13 RF Mixers applications.
- Laptops
- Marine Navigation
- Avionics
- Cellular Phones with GPS
- Notebook PC
- Ultra-Mobile PC
- Recreational
- Marine Navigation
- Avionics
- GPS
