TI REG1117A-2.5G4

Manufacturer No:

REG1117A-2.5G4

Manufacturer:

Package:

SOT-223

Description:

Fixed 2.3mm PMIC 4 SOT-223

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

REG1117A-2.5G4 information

TI REG1117A-2.5G4 technical specifications, attributes, parameters and parts with similar specifications to TI REG1117A-2.5G4.

Type
Parameter

Package / Case
SOT-223

Surface Mount
YES

Number of Pins
4

Packaging
Rail/Tube

JESD-609 Code
e4

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
4

ECCN Code
EAR99

Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)

Max Operating Temperature
125°C

Min Operating Temperature
0°C

Subcategory
Other Regulators

Technology
BIPOLAR

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
2.3mm

Pin Count
4

Number of Outputs
1

Output Type
Fixed

Max Output Current
1A

Polarity
Positive

Current - Output
1A

Accuracy
1 %

Max Output Voltage
2.5V

Voltage - Output
2.5V

Output Voltage 1
2.5V

Min Input Voltage
3.8V

Current - Input Bias
4mA

Max Input Voltage
15V

Dropout Voltage
1.2V

Dropout Voltage1-Nom
1.2V

Min Output Voltage
2.5V

Voltage Tolerance-Max
2%

Min Current Limit
1A

Output Voltage Accuracy
1 %

Line Regulation-Max (%/V)
0.007%

Length
6.5mm

Width
3.5mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for TI REG1117A-2.5G4.

REG1117A-2.5G4 Overview

This Voltage Regulator IC comes inRail/Tube packaging. This battery regulator is contained in a SOT-223 package. There are 4 terminations on the gadget. The IC chip's output type is Fixed. Its current output stands at 1A. IC voltage regulator has a sum of 4 pins. To ensure prompt, sufficient performance, this part features 1 outputs in total. Its dropout voltage is 10 volts. The component's pin number remains 4. This regulator IC is a typical Other Regulators. It works in 1A output current at mostIt operates in the 4mA Quiescent Current state. The regulator operates with a maximum operating temperature of 125°C. At the very least, the voltage regulator IC works with a 0°C operating temperature. On a system basis, this IC voltage regulator is able to output 2.5V volts generally.

REG1117A-2.5G4 Features

1.2V dropout voltage
Other Regulators subtageroy
The maximum operating temperature of 0°C

REG1117A-2.5G4 Applications

There are a lot of Texas Instruments
REG1117A-2.5G4 Linear Voltage Regulators applications.

Home electric appliance
Battery-powered device
Communication device
Personal communication device
Portable telephone
Electronic notebook
Camera
Video equipment
CPU power supply
Switching regulator
