XP Power RDH60072WS28
XP Power RDH60072WS28

XP Power RDH60072WS28

Manufacturer No:

RDH60072WS28

Manufacturer:

XP Power

Package:

Full Brick

Description:

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

RDH60072WS28 information

XP Power RDH60072WS28 technical specifications, attributes, parameters and parts with similar specifications to XP Power RDH60072WS28.

  • Type
  • Parameter
  • Factory Lead Time
  • 14 Weeks
  • Mounting Type
  • Through Hole
  • Package / Case
  • Full Brick
  • Operating Temperature
  • -40°C~100°C
  • Series
  • RDH600 (600W)
  • Size / Dimension
  • 4.60Lx2.40W x 0.50 H 116.8mmx61.0mmx12.7mm
  • Feature
  • Remote On/Off, OCP, OTP, OVP, SCP, UVLO
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Type
  • Isolated Module
  • Applications
  • Railway
  • Number of Outputs
  • 1
  • Efficiency
  • 88%
  • Voltage - Isolation
  • 3kV
  • Voltage - Input (Max)
  • 160V
  • Voltage - Output 1
  • 28V
  • Voltage - Input (Min)
  • 43V
  • Current - Output (Max)
  • 21.4A
  • Output Power
  • 600W
  • Height
  • 12.7mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for XP Power RDH60072WS28.

Datasheets:

Environmental Information:

RDH60072WS28                             DESCRIPTION

Isolation in terms of DC/DC converters refers to galvanic isolation which means that there is no metallic / direct conduction path between two parts of the circuit. The isolation will always present a barrier between the input stage and the output stage and may be required for circuit functionality, safety, or both.


RDH60072WS28                             Feature

? Wide 4:1 Input Range

? Covers 72 & 110VDC for Rail Applications

? Complies with EN50155

? Meets EN50121-3-2

? Single Output

? Industry Standard Full Brick

? -40°C to +100°C Operation

? Output Trim 60-110%

? Remote On/Off

? 3 Year Warranty


RDH60072WS28                            APPLICATIONS

Portable, battery-powered equipment

Automotives

Power supplies

Data acquisition systems

Instrumentation and process control

Energy management
