Renesas R5S72691W266BG#U0

Manufacturer No:

R5S72691W266BG#U0

Manufacturer:

Renesas

Package:

272-FBGA

Description:

ROMless SH2A-FPU 32-Bit Microcontroller SuperH® SH7260 Series 272 Pin 266MHz 3.3V 272-FBGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

R5S72691W266BG#U0 information

Renesas R5S72691W266BG#U0 technical specifications, attributes, parameters and parts with similar specifications to Renesas R5S72691W266BG#U0.

Type
Parameter

Factory Lead Time
20 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
272-FBGA

Number of Pins
272

Operating Temperature
-20°C~85°C TA

Packaging
Tray

Series
SuperH® SH7260

Published
2012

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
272

Subcategory
Microcontrollers

Technology
CMOS

Terminal Position
BOTTOM

Terminal Form
BALL

Supply Voltage
3.3V

Frequency
266MHz

Pin Count
272

Operating Supply Voltage
3.3V

Supply Voltage-Max (Vsup)
3.6V

Interface
CAN, EBI/EMI, I2C, SCI, SPI, UART, USB

Oscillator Type
External

RAM Size
2.5M x 8

Voltage - Supply (Vcc/Vdd)
3V~3.6V

uPs/uCs/Peripheral ICs Type
MICROCONTROLLER, RISC

Core Processor
SH2A-FPU

Peripherals
DMA, POR, PWM, WDT

Program Memory Type
ROMless

Core Size
32-Bit

Connectivity
CANbus, EBI/EMI, I2C, IEBus, SCI, SIO, SPI, USB

Bit Size
32

Data Converter
A/D 8x10b

Watchdog Timer
Yes

Has ADC
YES

DMA Channels
YES

Data Bus Width
32b

PWM Channels
YES

Number of Timers/Counters
7

Address Bus Width
26

ROM (words)
0

CPU Family
SH-2A

Number of UART Channels
8

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Renesas R5S72691W266BG#U0.

ConflictMineralStatement:

nec-dn1c100m1s-conflictmineralstatement-8243.pdf

R5S72691W266BG#U0 Overview

The package is in 272-FBGA format. The MCU has 149 I/O ports. There is a mounting type Surface Mount associated with this Microcontroller. This Microcontroller is based on the 32-Bit core. There is a memory type of ROMless in its program memory. The temperature range that this Microcontroller operates at is -20°C~85°C TA. The electrical component that you are looking at belongs to the SuperH® SH7260 series of components. The SH2A-FPU Core Processor powers the device and is one of its key features. This Microcontroller belongs to the MICROCONTROLLER, RISC uPs/uCs/peripheral ICs type. During the manufacture of the IC chip, there is a number 272 of terminations. A 32-bit operation is performed by this part. There is an output of 3.3V volts from the Microcontroller chip. A total of YES DMA channels are available on MCU chip. It exhibits good efficiency when it operates at a frequency of 266MHz and it is able to operate at a high frequency. It is possible for the device to work with the motor using the PWM channel YES. It is possible to access the 272 pins on the chip through the 272 pins. It is equipped with 7 timers and counters. It consists of 272 pins. As far as the CPU is concerned, it is embedded with the the SH-2A family of processors. The device features 8 UART channels.
