Renesas R5F213J6CNNP#U0

Manufacturer No:

R5F213J6CNNP#U0

Manufacturer:

Renesas

Package:

36-WFQFN Exposed Pad

Description:

32KB 32K x 8 FLASH R8C 16-Bit Microcontroller R8C/3x/3JC Series R5F213 36 Pin 20MHz 3V 36-WFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

R5F213J6CNNP#U0 information

Renesas R5F213J6CNNP#U0 technical specifications, attributes, parameters and parts with similar specifications to Renesas R5F213J6CNNP#U0.

Type
Parameter

Factory Lead Time
20 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
36-WFQFN Exposed Pad

Number of Pins
36

Operating Temperature
-20°C~85°C TA

Packaging
Tray

Series
R8C/3x/3JC

Published
2010

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
36

Subcategory
Microcontrollers

Max Power Dissipation
500mW

Technology
CMOS

Terminal Position
QUAD

Supply Voltage
3V

Frequency
20MHz

Base Part Number
R5F213

Pin Count
36

Interface
I2C, LIN, UART, USART

Memory Size
32kB

Oscillator Type
Internal

RAM Size
2.5K x 8

Voltage - Supply (Vcc/Vdd)
1.8V~5.5V

uPs/uCs/Peripheral ICs Type
MICROCONTROLLER

Core Processor
R8C

Peripherals
POR, PWM, Voltage Detect, WDT

Program Memory Type
FLASH

Core Size
16-Bit

Program Memory Size
32KB 32K x 8

Connectivity
I2C, LINbus, SIO, SSU, UART/USART

Bit Size
16

Data Converter
A/D 10x10b; D/A 2x8b

Watchdog Timer
Yes

Has ADC
YES

DMA Channels
NO

Data Bus Width
16b

PWM Channels
YES

Number of Timers/Counters
5

CPU Family
R8C

Number of UART Channels
3

Number of ADC Channels
10

Number of I2C Channels
2

Height
750μm

Length
6.1mm

Download datasheets and manufacturer documentation for Renesas R5F213J6CNNP#U0.

ConflictMineralStatement:

nec-dn1c100m1s-conflictmineralstatement-8243.pdf

R5F213J6CNNP#U0 Overview

Packaged in a 36-WFQFN Exposed Pad format. A total of 31 I/Os are on the Microcontroller. Surface Mount is the mounting type of the Microcontroller that is attached to the panel. This Microcontroller is based on a core called 16-Bit. The type of its program memory is FLASH. In this Microcontroller, temperature is controlled within the range -20°C~85°C TA. A R8C/3x/3JC series electrical component is used in this application. This program has a program memory of 32KB 32K x 8 bytes, which is the size of the program. With a R8C Core Processor, Microcontroller is fast and efficient. ICs for MICROCONTROLLER uPs/uCs/peripheral parts. There are 36 terminations on the IC chip, which means there are 36 terminations on the integrated circuit chip. In addition, MCU chip comes with a 16-bit size. Microcontroller chip has outputs of 3V volts. The system has NO channels for DMA communication. There is 32kB memory size assigned to the part. Alternatives can be found by searching through the base part number R5F213 to find them. At a frequency of 20MHz, Microcontroller can operate efficiently. This MCU Chip uses YES PWM channels to operate. Chips have 36 pins. There are 5 timers/counters in this device. In total, it has 36 pins. The R8C CPU family is embedded in the device, so it can handle a wide range of operations. It has 8 channels that can be accessed through UART. It consists of 10 channels in total for the ADC. 2 channels of I2C have been incorporated into the design of the part.
