Renesas R5F10JGCANA#U0

Manufacturer No:

R5F10JGCANA#U0

Manufacturer:

Renesas

Package:

48-WFQFN Exposed Pad

Description:

32KB 32K x 8 FLASH RL78 16-Bit Microcontroller RL78/G1C Series 48 Pin 24MHz 3V 48-WFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

R5F10JGCANA#U0 information

Renesas R5F10JGCANA#U0 technical specifications, attributes, parameters and parts with similar specifications to Renesas R5F10JGCANA#U0.

Type
Parameter

Factory Lead Time
20 Weeks

Mounting Type
Surface Mount

Package / Case
48-WFQFN Exposed Pad

Surface Mount
YES

Number of Pins
48

Operating Temperature
-40°C~85°C TA

Packaging
Tray

Series
RL78/G1C

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
48

Additional Feature
OPERATES AT 2.4 V MINIMUM SUPPLY AT 16 MHZ

HTS Code
8542.31.00.01

Technology
CMOS

Terminal Position
QUAD

Supply Voltage
3V

Terminal Pitch
0.5mm

Frequency
24MHz

Pin Count
48

Supply Voltage-Max (Vsup)
5.5V

Supply Voltage-Min (Vsup)
2.7V

Interface
I2C, UART, USART, USB

Memory Size
32kB

Number of I/O
38

RAM Size
5.5K x 8

Voltage - Supply (Vcc/Vdd)
2.4V~5.5V

uPs/uCs/Peripheral ICs Type
MICROCONTROLLER

Core Processor
RL78

Peripherals
DMA, LVD, POR, PWM, WDT

Program Memory Type
FLASH

Core Size
16-Bit

Program Memory Size
32KB 32K x 8

Connectivity
CSI, I2C, UART/USART, USB

Bit Size
16

Data Converter
A/D 9x8/10b

Watchdog Timer
Yes

Has ADC
YES

DMA Channels
YES

Data Bus Width
16b

PWM Channels
YES

DAC Channels
NO

Number of Timers/Counters
9

ROM (words)
32768

EEPROM Size
2K x 8

On Chip Program ROM Width
8

RAM (bytes)
5632

Download datasheets and manufacturer documentation for Renesas R5F10JGCANA#U0.

Datasheets:

renesaselectronicsamerica-r5f10jbcanau0-datasheets-5752.pdf

ConflictMineralStatement:

nec-dn1c100m1s-conflictmineralstatement-8243.pdf

R5F10JGCANA#U0 Overview

The package has a 48-WFQFN Exposed Pad shape. With 38 I/Os, it's pretty good. The Microcontroller's mounting type is Surface Mount and this IC chip has the following features. As the name implies, this Microcontroller is based on the 16-Bit core. As far as its program memory type is concerned, it is FLASH. Temperatures within -40°C~85°C TA range are measured by this Microcontroller. The RL78/G1C series is comprised of this electrical component. The electronic part has a program memory size of 32KB 32K x 8. There's a RL78 Core Processor inside. The IC chip fits into the MICROCONTROLLER uPs/uCs/Peripheral ICs category. There are 48 terminations on the IC chip. 16-bits are the size of the data that comes with MCU. A 3V volt supply is provided by the Microcontroller chip. In addition to that, MCU chip has YES DMA channels. Its memory size is 32kB. An effective performance can be achieved at a frequency of 24MHz. There are a total of YES channels in the device. It is possible to access the 48 pins on the chip. In total, it has 9 timers and counters in it. A total of 48 pins are included in the package. As an example, there is a feature called OPERATES AT 2.4 V MINIMUM SUPPLY AT 16 MHZ to name only a few.

R5F10JGCANA#U0 Features

48-WFQFN Exposed Pad package
Mounting type of Surface Mount
