Manufacturer No:

POWERSTEP01

Manufacturer:

ST

Package:

VFQFPN-14

Description:

Description: System-in-package integrating microstepping controller and 10 A power MOSFETs

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

POWERSTEP01 information

ST POWERSTEP01 technical specifications, attributes, parameters and parts with similar specifications to ST POWERSTEP01.

  • Type
  • Parameter
  • RoHS Status
  • RoHS Compliant
  • Part Life Cycle Code
  • Active
  • Ihs Manufacturer
  • STMICROELECTRONICS
  • Package Description
  • VFQFPN-14
  • Reach Compliance Code
  • compliant
  • ECCN Code
  • EAR99
  • HTS Code
  • 8542.39.00.01
  • Factory Lead Time
  • 17 Weeks
  • Samacsys Manufacturer
  • STMicroelectronics
  • Additional Feature
  • OTHER NOMINAL VOLTAGE=5V
  • Analog IC - Other Type
  • STEPPER MOTOR CONTROLLER
  • JESD-30 Code
  • R-XQCC-N89
  • JESD-609 Code
  • e3
  • Length
  • 14 mm
  • Moisture Sensitivity Level
  • 3
  • Number of Functions
  • 1
  • Number of Terminals
  • 89
  • Operating Temperature-Max
  • 125 °C
  • Operating Temperature-Min
  • -25 °C
  • Package Body Material
  • UNSPECIFIED
  • Package Code
  • HQCCN
  • Package Shape
  • RECTANGULAR
  • Package Style
  • CHIP CARRIER, HEAT SINK/SLUG
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Surface Mount
  • YES
  • Temperature Grade
  • OTHER
  • Terminal Finish
  • Matte Tin (Sn)
  • Terminal Form
  • NO LEAD
  • Terminal Position
  • QUAD
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Width
  • 11 mm

Download datasheets and manufacturer documentation for ST POWERSTEP01.

Datasheets:

POWERSTEP01 Description


The powerSTEP01 is a system-in-package integrating 8 N-channel 16 m? MOSFETs for stepper applications up to 85 V with an SPI programmable controller, providing fully digital control of the motion through a speed profile generation and positioning calculations.



POWERSTEP01 Features


  • Operating voltage: 7.5 V - 85 V

  • Dual full-bridge with RDS(on) = 16 m?

  • 10 ARMS maximum output current

  • Adjustable output slew rate

  • Programmable speed profile

  • Up to 1/128 microstepping

  • Sensorless stall detection

  • Integrated voltage regulators

  • SPI interface

  • Low quiescent standby currents

  • Programmable non-dissipative overcurrent protection

  • Overtemperature protection



POWERSTEP01 Applications


  • High power bipolar stepper motor

? Stage lighting

? Surveillance systems

? Textile and sewing machines

? Pick and place machines


User Guide
