PJ-037AH-SMT-TR information

CUI PJ-037AH-SMT-TR technical specifications, attributes, parameters and parts with similar specifications to CUI PJ-037AH-SMT-TR.

  • Type
  • Parameter
  • Factory Lead Time
  • 11 Weeks
  • Contact Material
  • Brass, Copper Alloy
  • Contact Plating
  • Nickel
  • Mount
  • Surface Mount, Through Hole
  • Mounting Type
  • Surface Mount, Right Angle; Through Hole
  • Package / Case
  • SMD/SMT
  • Housing Material
  • Polyamide (PA6T), Nylon 6T
  • Contact Material - Plating
  • Silver
  • Operating Temperature
  • -25°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2011
  • Feature
  • Board Guide, Solder Retention
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • Jack
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -25°C
  • Color
  • Black
  • Gender
  • Male
  • Voltage - Rated
  • 24VDC
  • Current Rating (Amps)
  • 5A
  • Orientation
  • Horizontal
  • Shielding
  • Unshielded
  • Number of Conductors
  • 2
  • Contact Gender
  • Male
  • Housing Color
  • Black
  • Insulation Resistance
  • 100MOhm
  • Number of Positions/Contacts
  • 2 Conductors, 3 Contacts
  • Internal Switch(s)
  • Single Switch, Normally Closed
  • Body Color
  • Black
  • Industry Recognized Mating Diameter
  • 2.10mm ID (0.083), 5.50mm OD (0.217)
  • Actual Diameter
  • 0.079 (2.00mm ID), 0.248 (6.30mm OD)
  • Mating Length/Depth
  • 0.360 9.15mm
  • Material Flammability Rating
  • UL94 V-0
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0

Download datasheets and manufacturer documentation for CUI PJ-037AH-SMT-TR.

Datasheets:

Description:

The CUI Devices PJ-037AH-SMT-TR is a 2x5.5mm power connector barrel with solder terminals. It is designed for use in a variety of applications, including consumer electronics, industrial equipment, and medical devices. The connector features a robust design with a secure locking mechanism and a high current rating of up to 10A. It is also RoHS compliant and UL recognized.
