Microchip PIC24FJ256DA210-I/BG

Manufacturer No:

PIC24FJ256DA210-I/BG

Manufacturer:

Microchip

Package:

Description:

16 MIPS, 256KB Flash, 96KB RAM, 100 pins, USB, Graphics Controller

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PIC24FJ256DA210-I/BG information

Microchip PIC24FJ256DA210-I/BG technical specifications, attributes, parameters and parts with similar specifications to Microchip PIC24FJ256DA210-I/BG.

Type
Parameter

CPU Type
16-bit PIC MCU

CPU Speed Max MHz (megahertz)
16

Program Memory Size (KB)
256

Multiple Flash Panels
No

Direct Memory Access (DMA) Channels
2

Temp. Range Min.(C°)
-40

Temp. Range Max.(C°)
85

Operation Voltage Min.(V)
2.2

Operation Voltage Max.(V)
3.6

Pin Count
100

Low Power
No

Number of Comparators
3

ADC Modules
1

ADC Channels
24

ADC Resolution Max
10

ADC Sampling Rate (ksps)
500

Number of DACs
0

DAC outputs
0

Max DAC Resolution (bits)
0

Hardware RTCC
No

Motor Control PWM Channels
0

SMPS PWM Channels
0

Number of PWM Time Bases
9

Output Compare Channels
9

Number of CAN Modules
0

Type of CAN module Max
None

Crypto Engine
No

Quadrature Encoder Interface (QEI)
0

Segment LCD
0

LCD/Graphics Interface
Yes

Configurable Logic Cell Modules (CLC /CCL)
0

Peripheral Pin Select (PPS)/Pin Muxing
Yes

Supported in MPLAB Code Configurator
Yes

Download datasheets and manufacturer documentation for Microchip PIC24FJ256DA210-I/BG.

The PIC24F-DA family features integrated graphics acceleration and a display controller to directly drive displays up to 4.3" WQVGA with 480 × 272 resolution. Ideal for Graphical interface applications that can benefit from the integrated Graphics, 96K byte RAM for frame buffer, mTouch, USB and other peripherals.

Graphics Application Design Center

Note: Due to limited ecosystem support, we do not recommend this part for new designs. In accordance with Microchip's policy, this part will remain in production.

3x Graphics Hardware Acceleration Units
Color Look-up Table (CLUT) with Maximum of 256 Entries
Direct Interface to Monochrome, C-STN, TFT, OLED
Resolution up to 640x480 @30Hz, 16 bpp, or 480x272 @60Hz, 16 bpp
Large integrated 96KB SRAM

USB v2.0 On-the-Go (OTG) compliant
Dual role capable - can act as either Host or Device
Low speed(1.5Mb/s) and full speed(12 Mb/s) operation in host mode
Full speed USB operaton in Device mode

Up to 24x, Capacitive touch sensing
Up to 24x, 10-Bit, ADC at 500 ksps
3x Analog Comparators with Programmable Input/Output Configuration

On-Chip Voltage Regulator of 1.8V
Switch between Clock Sources in Real Time
Idle, Sleep and Doze modes with Fast Wake-up and Two-Speed Start-up
Run Mode: 800 uA/MIPS, 3.3V Typical
Sleep mode Current Down to 20 uA, 3.3V Typical
Standby Current with 32 kHz Oscillator: 22 uA, 3.3V Typical
