TI PGA207UAE4

Manufacturer No:

PGA207UAE4

Manufacturer:

Package:

SOIC

Description:

1 Channels 17mA per Channel 100pA 84 dB Instrumentational OP Amps 16 Pins SOIC

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PGA207UAE4 information

TI PGA207UAE4 technical specifications, attributes, parameters and parts with similar specifications to TI PGA207UAE4.

Type
Parameter

Package / Case
SOIC

Surface Mount
YES

Number of Pins
16

Weight
420.395078mg

JESD-609 Code
e4

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
NICKEL PALLADIUM GOLD

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Instrumentation Amplifier

Technology
BIPOLAR

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
15V

Pin Count
16

Number of Elements
3

Temperature Grade
INDUSTRIAL

Number of Channels
1

Max Supply Voltage
36V

Min Supply Voltage
9V

Quiescent Current
12.4mA

Slew Rate
25 V/μs

Amplifier Type
INSTRUMENTATION AMPLIFIER

Common Mode Rejection Ratio
84 dB

Current - Input Bias
100pA

Output Current per Channel
17mA

Input Offset Voltage (Vos)
1mV

Bandwidth
5MHz

Neg Supply Voltage-Nom (Vsup)
-15V

Settling Time
3.5 μs

Max Dual Supply Voltage
18V

-3db Bandwidth
5MHz

Min Dual Supply Voltage
4.5V

Dual Supply Voltage
15V

Voltage Gain-Min
1

Input Voltage Noise Density
18nV/sqrt Hz

Voltage Gain-Nom
2

Non-linearity-Max
0.005%

Voltage Gain-Max
10

Height Seated (Max)
2.65mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for TI PGA207UAE4.
