Advanced Photonix PDB-C216
Advanced Photonix PDB-C216

Advanced Photonix PDB-C216

Manufacturer No:

PDB-C216

Manufacturer:

Advanced Photonix

Package:

Array - 16 Element

Description:

Through Hole -20°C~75°C Bulk Wavelength: 950nm Array - 16 Element 50V 2.24mm2 (x16) 13ns 5nA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PDB-C216 information

Advanced Photonix PDB-C216 technical specifications, attributes, parameters and parts with similar specifications to Advanced Photonix PDB-C216.

  • Type
  • Parameter
  • Factory Lead Time
  • 14 Weeks
  • Mounting Type
  • Through Hole
  • Package / Case
  • Array - 16 Element
  • Number of Pins
  • 18
  • Operating Temperature
  • -20°C~75°C
  • Packaging
  • Bulk
  • Published
  • 2005
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Response Time
  • 13ns
  • Voltage - DC Reverse (Vr) (Max)
  • 50V
  • Rise Time
  • 15ns
  • Max Reverse Voltage (DC)
  • 50V
  • Wavelength
  • 950nm
  • Dark Current
  • 5nA
  • Spectral Range
  • 350nm ~ 1100nm
  • Active Area
  • 2.24mm2 (x16)
  • Color - Enhanced
  • Blue
  • Height
  • 4.5mm
  • Length
  • 25.2mm
  • Width
  • 10.8mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Advanced Photonix PDB-C216.

Datasheets:

PDB-C216 Overview


These photodiodes are packaged in the Bulk to protect them from damage. The photodiodes are put into Array - 16 Element packages for safety protection. In reverse-bias mode on a continual basis, the maximum amount of voltage the photodiodes can withstand is 50V. The voltage for the photodiodes should not exceed 50V in reverse-bias mode on a continual basis. The photodiodes have 18 pins. Even in the absence of light input, a photodiode occurs 5nA current.

PDB-C216 Features


Moisture Sensitivity Level (MSL): 1 (Unlimited)
Operating Temperature: -20°C~75°C
Packaging: Bulk
Spectral Range: 350nm ~ 1100nm
Response Time: 13ns


PDB-C216 Applications


There are a lot of Advanced Photonix
PDB-C216 Photodiodes applications.


  • High speed photo detector
  • Infrared remote control
  • Infrared data transmission
  • Photo interrupters
  • Shaft encoders
  • Electronic Equipment
  • Industrial Automation
  • Machine Controls
  • Light Barriers
  • Vision Controls
