PD55003L-E information

ST PD55003L-E technical specifications, attributes, parameters and parts with similar specifications to ST PD55003L-E.

  • Type
  • Parameter
  • Lifecycle Status
  • ACTIVE (Last Updated: 7 months ago)
  • Factory Lead Time
  • 11 Weeks
  • Mount
  • Surface Mount
  • Package / Case
  • 8-PowerVDFN
  • Number of Pins
  • 8
  • Packaging
  • Tape & Reel (TR)
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 5
  • Termination
  • SMD/SMT
  • ECCN Code
  • EAR99
  • Terminal Finish
  • MATTE TIN
  • Max Operating Temperature
  • 150°C
  • Min Operating Temperature
  • -65°C
  • Additional Feature
  • HIGH RELIABILITY
  • Subcategory
  • FET General Purpose Power
  • Voltage - Rated DC
  • 12V
  • Max Power Dissipation
  • 14W
  • Terminal Position
  • QUAD
  • Peak Reflow Temperature (Cel)
  • 260
  • Current Rating
  • 2.5A
  • Frequency
  • 500MHz
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Pin Count
  • 5
  • JESD-30 Code
  • S-PQCC-N5
  • Number of Elements
  • 1
  • Element Configuration
  • Single
  • Operating Mode
  • ENHANCEMENT MODE
  • Case Connection
  • SOURCE
  • Current - Test
  • 50mA
  • Transistor Application
  • AMPLIFIER
  • Drain to Source Voltage (Vdss)
  • 40V
  • Polarity/Channel Type
  • N-CHANNEL
  • Transistor Type
  • LDMOS
  • Continuous Drain Current (ID)
  • 2.5A
  • Gate to Source Voltage (Vgs)
  • 15V
  • Gain
  • 19dB
  • Max Output Power
  • 3W
  • Dual Supply Voltage
  • 40V
  • Input Capacitance
  • 34pF
  • FET Technology
  • METAL-OXIDE SEMICONDUCTOR
  • Nominal Vgs
  • 5 V
  • Voltage - Test
  • 12.5V
  • Height
  • 880?m
  • Length
  • 5mm
  • Width
  • 5mm
