Trinamic Motion Control GmbH PD42-1-1240-TMCL

Manufacturer No:

PD42-1-1240-TMCL

Manufacturer:

Trinamic Motion Control GmbH

Package:

Description:

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PD42-1-1240-TMCL information

Trinamic Motion Control GmbH PD42-1-1240-TMCL technical specifications, attributes, parameters and parts with similar specifications to Trinamic Motion Control GmbH PD42-1-1240-TMCL.

Type
Parameter

Factory Lead Time
8 Weeks

Mounting Hole Spacing
1.220 (31.00mm)

Operating Temperature
-20°C~50°C

Series
PANdrive?

Published
2018

Size / Dimension
Square - 1.654 x 1.654 42.00mmx42.00mm

Feature
Integrated Controller, Flatted Shaft

Part Status
Active

Moisture Sensitivity Level (MSL)
Not Applicable

Type
Hybrid

Voltage - Rated
24VDC

Current Rating (Amps)
2A

Termination Style
Wire Leads with Connector

Accuracy
±5%

Coil Resistance
1Ohm

Coil Type
Bipolar

Step Angle
1.8°

Steps per Revolution
200

Torque - Holding (oz-in / mNm)
31.15 / 220

NEMA Frame Size
17

Rotor Inertia
35gcm2

Diameter - Shaft
0.197 (5.00mm)

Length - Shaft and Bearing
0.945 24.00mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Trinamic Motion Control GmbH PD42-1-1240-TMCL.

Datasheets:

trinamicmotioncontrolgmbh-pd4221240tmcl-datasheets-3272.pdf

PD42-1-1240-TMCL Description

PD42-1-1240-TMCL is a high-performance stepper motor designed for use in various industrial applications. It features a NEMA 17 frame size, a 1.8° step angle, and a holding torque of 0.45 Nm. The motor is designed with a thermally optimized structure that allows for a high torque density while keeping noise and vibration to a minimum. With a maximum speed of 4000 RPM and an operating voltage range of 12-40 VDC, PD42-1-1240-TMCL is suitable for use in a wide range of applications, including 3D printing, robotics, CNC machines, and more. The motor's four-wire connection makes it easy to integrate into existing systems, and its low current consumption helps to extend the life of the motor and reduce power consumption.

PD42-1-1240-TMCL Features

Bipolar stepper motor with four-wire connection

NEMA 17 frame size (42 x 42 mm)

1.8° step angle (200 steps per revolution)

Holding torque of 0.45 Nm (64 oz-in)

Maximum speed of 4000 RPM

Operating voltage range of 12-40 VDC

Peak current of 1.2 A

Thermally optimized design with a high torque density

Low noise and vibration

PD42-1-1240-TMCL Applications

3D printers

Robotics

CNC machines

Textile machines

Packaging machines

Industrial automation

Medical devices
