PCA9571GUX information

NXP PCA9571GUX technical specifications, attributes, parameters and parts with similar specifications to NXP PCA9571GUX.

  • Type
  • Parameter
  • Factory Lead Time
  • 7 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 12-XFQFN
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2011
  • JESD-609 Code
  • e4
  • Feature
  • POR
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 12
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Technology
  • CMOS
  • Voltage - Supply
  • 1.1V~3.6V
  • Terminal Position
  • QUAD
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Supply Voltage
  • 2.2V
  • Terminal Pitch
  • 0.4mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Base Part Number
  • PCA9571
  • Pin Count
  • 12
  • JESD-30 Code
  • R-PQCC-N12
  • Interface
  • I2C
  • Number of I/O
  • 8
  • Clock Frequency
  • 1MHz
  • Interrupt Output
  • No
  • Length
  • 2mm
  • Height Seated (Max)
  • 0.5mm
  • Width
  • 1.7mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NXP PCA9571GUX.

Datasheets:

Environmental Information:

PCA9571GUX Overview


The board has been programmed with 8 I/Os.In the packaging with the 12-XFQFN, there is a device enclosed in the package.There is an option of the Tape & Reel (TR) case that you can choose from.There is a vote within the 1.1V~3.6V range that is supplied.The recommended mounting type is Surface Mount, which makes it suitable for most applications.A device works when its operating temperature ranges from -40°C~85°C to -40°C~85°C.In order to achieve a good performance, it works at a frequency of 1MHz.As a whole, it consists of 12 terminations.In total, there are 12 pins on the part.There is voltage present at 2.2V as a result of the device.It is utilized to run 260 on this part due to its peak reflow temperature.The PCA9571 family of parts can be used to identify related parts.In addition, POR can also be founded when using this device.
