APEX PA10M

Manufacturer No:

PA10M

Manufacturer:

APEX

Package:

TO-3-8

Description:

5A per Channel 12nA 100 dB Instrumentational OP Amps 0.03?A 20V~90V ±10V~45V PA10 2 Pins TO-3-8

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

PA10M information

APEX PA10M technical specifications, attributes, parameters and parts with similar specifications to APEX PA10M.

Type
Parameter

Factory Lead Time
8 Weeks

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
TO-3-8

Operating Temperature
-55°C~125°C

Packaging
Tube

Series
Apex Precision Power®

Published
2013

JESD-609 Code
e0

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
8

ECCN Code
EAR99

Terminal Finish
Tin/Lead (Sn/Pb)

Subcategory
Operational Amplifier

Technology
HYBRID

Terminal Position
BOTTOM

Terminal Form
PIN/PEG

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
40V

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
PA10

Pin Count
2

Qualification Status
Not Qualified

Power Supplies
+-40V

Number of Circuits
1

Operating Supply Current
15mA

Supply Current-Max
75mA

Slew Rate
3V/?s

Architecture
VOLTAGE-FEEDBACK

Amplifier Type
Power

Common Mode Rejection Ratio
100 dB

Current - Input Bias
12nA

Voltage - Supply, Single/Dual (±)
20V~90V ±10V~45V

Output Current per Channel
5A

Input Offset Voltage (Vos)
2mV

Gain Bandwidth Product
4MHz

Neg Supply Voltage-Nom (Vsup)
-40V

Unity Gain BW-Nom
4000 kHz

Average Bias Current-Max (IIB)
0.03?A

Low-Offset
NO

Frequency Compensation
YES

Supply Voltage Limit-Max
50V

Bias Current-Max (IIB) @25C
0.03?A

Screening Level
MIL-STD-883 Class B (Modified)

Neg Supply Voltage-Max (Vsup)
-50V

Download datasheets and manufacturer documentation for APEX PA10M.

Datasheets:

apexmicrotechnology-pa10m-datasheets-2737.pdf

apexmicrotechnology-sa50ce-datasheets-3313.pdf

PA10M Overview

Op amp is packaged in TO-3-8 case. Op amps are Power types of amplifier on the chip. Instrumentation amplifier is delivered in a Tube case. The number of terminations approaches 8. Linear amplifier has a total of 2 pins. Please take in mind that op amp should be run at 40V. Instrumentation amplifier is a part of Operational Amplifier. Regarding input offset voltage, buffer amplifier rates 2mV voltage. Through Hole is the recommended mounting type of operational amplifiers. With regard to operating temperature, op amp ranges -55°C~125°C. Operational amplifier can operate supply current at 15mA. There are 1 circuits on op amps. Apex Precision Power® corresponds to linear amplifier's series. To conduct electronic part voltage gain higher than 63000.

PA10M Features

2 Pins
supply voltage of 40V

PA10M Applications

There are a lot of Apex Microtechnology
PA10M Instrumentational OP Amps applications.

Proportional operation circuits
Inverse/same-phase proportional circuit
Addition operation circuits
Subtraction operation circuits
single/dual op amp sum and difference circuits
Integrator circuits
Differentiator circuits
Logarithmic operation circuits
Exponential operation circuits
Multiplication circuits
