NTSX2102GU8H Information

NXP NTSX2102GU8H technical specifications, attributes, parameters and parts with similar specifications to NXP NTSX2102GU8H.

Type
Parameter

Factory Lead Time
10 Weeks

Mounting Type
Surface Mount

Package / Case
8-XFQFN

Surface Mount
YES

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

Published
2010

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
8

Type
Parameter

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.4mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
NTSX2102

Pin Count
QFN

JESD-30 Code
R-PQCC-N8

Download datasheets and manufacturer documentation for NXP NTSX2102GU8H.

Environmental Information:

nxpusainc-tef6657hnv102k-environmentalinformation-9391.pdf

PCN Packaging:

nxpusainc-sa605d01112-pcnpackaging-5569.pdf

Product Description:

The NTSX2102GU8H is a high-performance, bidirectional bus transceiver from NXP USA Inc. designed for surface-mount applications. This 2-channel, 50Mbps logic IC is a voltage-level translator that can operate in a wide temperature range of -40°C to 85°C. The device features auto-direction sensing, making it suitable for various applications where bidirectional data transfer is required.

Features:

Bidirectional operation: The NTSX2102GU8H can transmit and receive data in both directions, making it an ideal solution for applications where data needs to be exchanged between two devices.
High data rate: With a data rate of 50Mbps, this IC is capable of handling high-speed data transmission and reception.
Auto-direction sensing: The device automatically detects the direction of data transfer, eliminating the need for external direction sensing circuits.
Voltage-level translation: The IC can translate voltage levels between 1.65V and 5.5V, making it suitable for use in systems with different power supply voltages.
Open drain and tri-state outputs: The device features open drain and tri-state outputs, allowing for flexible output configuration and reducing the risk of output conflicts.

Applications:

Primary applications: The NTSX2102GU8H is suitable for use in high-speed data transmission and reception applications, such as:
Industrial control systems
Automotive electronics
Medical devices
Aerospace and defense systems
Secondary applications: The IC can also be used in other applications where bidirectional data transfer is required, such as:
Consumer electronics
Industrial automation
Networking equipment

Alternative Parts:

NTSX2102: The NTSX2102GU8H is a variant of the NTSX2102, which is a similar IC with a different package and pinout.

Embedded Modules:

Various industrial control systems: The NTSX2102GU8H is used in various industrial control systems, such as programmable logic controllers (PLCs), human-machine interfaces (HMIs), and industrial automation systems.
Automotive electronics: The IC is used in various automotive electronics applications, such as infotainment systems, navigation systems, and driver assistance systems.

FAQs:

Q: What is the operating temperature range of the NTSX2102GU8H? A: The operating temperature range of the NTSX2102GU8H is -40°C to 85°C.

Q: What is the maximum data rate of the IC? A: The maximum data rate of the NTSX2102GU8H is 50Mbps.

Q: Does the IC support auto-direction sensing? A: Yes, the NTSX2102GU8H features auto-direction sensing, eliminating the need for external direction sensing circuits.

Q: What is the package type of the IC? A: The package type of the NTSX2102GU8H is 8-XFQFN.

Q: Is the IC ROHS compliant? A: Yes, the NTSX2102GU8H is ROHS3 compliant.

Q: What is the supply voltage range of the IC? A: The supply voltage range of the NTSX2102GU8H is 1.65V to 5.5V.
