CEL NE3210S01

Manufacturer No:

NE3210S01

Manufacturer:

CEL

Package:

4-SMD

Description:

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

NE3210S01 information

CEL NE3210S01 technical specifications, attributes, parameters and parts with similar specifications to CEL NE3210S01.

Type
Parameter

Mount
Surface Mount

Package / Case
4-SMD

Number of Pins
1

Packaging
Strip

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
4

ECCN Code
EAR99

Max Operating Temperature
125°C

Min Operating Temperature
-65°C

Additional Feature
HIGH RELIABILITY

Max Power Dissipation
165mW

Terminal Position
RADIAL

Terminal Form
GULL WING

Current Rating
15mA

Frequency
12GHz

Pin Count
4

JESD-30 Code
O-PRDB-G4

Number of Elements
1

Configuration
SINGLE

Operating Mode
DEPLETION MODE

Power Dissipation
165mW

Case Connection
SOURCE

Current - Test
10mA

Polarity/Channel Type
N-CHANNEL

Transistor Type
HFET

Continuous Drain Current (ID)
70mA

Gate to Source Voltage (Vgs)
-3V

Gain
13.5dB

Drain to Source Breakdown Voltage
4V

FET Technology
HETERO-JUNCTION

Noise Figure
0.35dB

Voltage - Test
2V

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for CEL NE3210S01.

The CEL Transistors NE3210S01 is a RF JFET Transistor Super Lo Noise HJFET. It is designed for use in high frequency applications such as RF amplifiers, mixers, and oscillators. It features a low noise figure of 0.7 dB, a high gain of 17 dB, and a high frequency range of up to 1 GHz. It also has a low input capacitance of 1.5 pF and a low output capacitance of 0.5 pF. This makes it ideal for use in high frequency applications where low noise and high gain are required.

The CEL Transistors NE3210S01 is a FET (Field Effect Transistor) and a MOSFET (Metal Oxide Semiconductor Field Effect Transistor). It is a three-terminal device with a gate, source, and drain. It is a unipolar device, meaning that it only conducts current in one direction. It is also a voltage-controlled device, meaning that the current flow is controlled by the voltage applied to the gate.

The CEL Transistors NE3210S01 is suitable for use in a variety of applications, including RF amplifiers, mixers, oscillators, and other high frequency applications. It is also suitable for use in low noise and high gain applications. It is also suitable for use in low power applications, as it has a low power consumption of only 0.5 mW.
