ONSEMI NCP5810MUTXG

Manufacturer No:

NCP5810MUTXG

Manufacturer:

ONSEMI

Package:

12-UFLGA Exposed Pad

Description:

Obsolete DUAL Display Drivers ICs Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

NCP5810MUTXG information

ONSEMI NCP5810MUTXG technical specifications, attributes, parameters and parts with similar specifications to ONSEMI NCP5810MUTXG.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
12-UFLGA Exposed Pad

Number of Pins
12

Operating Temperature
-40°C~85°C

Packaging
Tape & Reel (TR)

Published
2007

JESD-609 Code
e4

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
12

ECCN Code
EAR99

Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)

Subcategory
Switching Regulator or Controllers

Voltage - Supply
2.7V~4.6V

Terminal Position
DUAL

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Number of Functions
2

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
40

Base Part Number
NCP5810

Pin Count
12

Number of Outputs
2

Efficiency
85 %

Output Voltage
4.6V

Output Type
Adjustable, Fixed

Input Voltage-Nom
3.7V

Configuration
Display Matrix

Analog IC - Other Type
SWITCHING REGULATOR

Operating Supply Current
1.5mA

Min Input Voltage
2.7V

Control Mode
CURRENT-MODE

Control Technique
PULSE WIDTH MODULATION

Display Type
AMOLED

Switching Frequency
1.75MHz

Length
3mm

Height Seated (Max)
0.6mm

Width
3mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ONSEMI NCP5810MUTXG.

NCP5810MUTXG Overview

Tape & Reel (TR)-like packaging has been used here.In version 12-UFLGA Exposed Pad, it is included.Display type AMOLED for this electrical device.Display drivers is mounted on the board wDisplay driversh the help of Surface Mount.Electrical parts like this operate at -40°C~85°C temperatures.Display drivers should be possible to operate Display drivers wDisplay driversh a 2.7V~4.6VV power source.Typically, 12 terminations match the impedance of transmission lines.Display drivers is a member of the NCP5810 family.Devices are made up entirely of 12 pins.A 12 pin is used in its design.The Surface Mount axis is used by the board manufacturer in order to mount this electronic component.If 1.5mA is to function properly, it must be supplied with current.The same applies to Switching Regulator or Controllers.This component provides 4.6V's output voltage.As far as I know, it is configured with 2 output.

NCP5810MUTXG Features

12-UFLGA Exposed Pad package
NCP5810 family
12 pin count
12 pins
2 output

NCP5810MUTXG Applications

There are a lot of ON Semiconductor
NCP5810MUTXG display drivers applications.

Portable lab instruments
Panel meters
Auto dashboard displays
Appliance control panels
Industrial Control Indicator
Relay Driver
Digital Clock, Thermometer, Counter, Voltmeter
Instrumentation Readouts
Instrumentation
Test Equipment
