Nuvoton NAU8814YG

Manufacturer No:

NAU8814YG

Manufacturer:

Nuvoton

Package:

24-VFQFN Exposed Pad

Description:

24 Termination 0.5mm CODEC emPowerAudio? Series 24 Pin 1.8V 24-VFQFN Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

NAU8814YG information

Nuvoton NAU8814YG technical specifications, attributes, parameters and parts with similar specifications to Nuvoton NAU8814YG.

Type
Parameter

Factory Lead Time
18 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
24-VFQFN Exposed Pad

Number of Pins
24

Operating Temperature
-40°C~85°C

Packaging
Tray

Series
emPowerAudio?

Published
2011

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
24

Type
Audio

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Supply Voltage
1.8V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Operating Supply Voltage
3.3V

Interface
I2S, Serial

Max Supply Voltage
5.5V

Operating Mode
SYNCHRONOUS

Sampling Rate
48 ksps

Voltage - Supply, Analog
2.5V~3.6V

Voltage - Supply, Digital
1.71V~3.6V

Number of D/A Converters
1

Resolution (Bits)
24 b

Sigma Delta
Yes

Number of ADCs / DACs
1 / 1

Filter
YES

S/N Ratio, ADCs / DACs (db) Typ
91 / 93

Companding Law
A/MU-LAW

Length
4mm

Height Seated (Max)
0.9mm

Width
4mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Nuvoton NAU8814YG.

NAU8814YG Overview

Space-saving reasons have led to it being packaged in a 24-VFQFN Exposed Pad package. Tray is the packaging method used. Because it is a type of Audio, it delivers high-efficiency performance in many applications. It uses a mounting type of Surface Mount. A -40°C~85°C operating performance setting allows it to operate normally. It is equipped with a total of 1 / 1 ADCs and DACs. Supply voltage 2.5V~3.6V is provided to the analog circuit. It is supplied with a voltage of 1.71V~3.6V to power the digital circuit. Signals are prevented from reflecting off the transmission line's terminations by using 24 terminations. 24-pin electronic devices are what it is. Mounted on a PCB based on the technology of Surface Mount. Supply voltage should be maintained at 5.5V. This device operates on 1.8V volts as its supply voltage. The device is able to operate at 3.3V voltages. In order to convert digital signals into analog signals, there are 1 D/A converters. There are a wide range of applications for this electronic component that belongs to the family of emPowerAudio? series.
