Microchip MTCH105T-I/ST

Manufacturer No:

MTCH105T-I/ST

Manufacturer:

Microchip

Package:

14-TSSOP (0.173, 4.40mm Width)

Description:

The MTCH105 is a low cost 5 channels capacitive proximity detector.

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MTCH105T-I/ST information

Microchip MTCH105T-I/ST technical specifications, attributes, parameters and parts with similar specifications to Microchip MTCH105T-I/ST.

Type
Parameter

Product Type
Proximity/Keys/Slider

Input Channels
5

Number of Keys Max
5

Proximity detection
Yes

Output Channels
5

Measurement Principle
Self Capacitance

Report Rate (pps)
0

Number of Touches
0

Power Modes
0

Interface
Digital Output

I/O, LED Drivers
0

Other Features
Moisture Tolerance

Voltage Min. (V)
2.10

Voltage Max. (V)
3.60

Download datasheets and manufacturer documentation for Microchip MTCH105T-I/ST.

Data Sheets:

d2663641430230c8337f215a67bef97a.pdf

ffadc2d3c9bbf76cd7008cc3d0c24290.pdf

Application Notes:

b9f0f87487e89565494f1e7a80215a04.pdf

The MTCH105 is a 5 channels Proximity/Touch controller with 5 simple digital outputs. The sensitivity and power mode can be configured. The MTCH105 device uses an advanced optimization algorithm to actively suppress noise from the signal to achieve reliable proximity/touch detection.

High Signal to Noise Ration (SNR)
Moisture/ Water resistance
Simple I/O interface with existing system
Adjustable Sensitivity with compensation for different sensor sizes
Multi Stage Active noise suppression filters
Automatic Environmental compensation
Support for wide range of sensor shape and size
Flexible Low Power Mode
