NXP MPX2053D

Manufacturer No:

MPX2053D

Manufacturer:

NXP

Package:

4-SIP Module

Description:

MPX2053 Series Differential Pressure Sensor Wheatstone Bridge -40°C~125°C 7.25PSI (50kPa) No Port 0 mV ~ 40 mV (10V) 10V~16V Temperature Compensated

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MPX2053D information

NXP MPX2053D technical specifications, attributes, parameters and parts with similar specifications to NXP MPX2053D.

Type
Parameter

Factory Lead Time
12 Weeks

Package / Case
4-SIP Module

Surface Mount
NO

Mounting Feature
THROUGH HOLE MOUNT

Operating Temperature
-40°C~125°C

Series
MPX2053

Published
2004

Feature
Temperature Compensated

Part Status
Active

Moisture Sensitivity Level (MSL)
Not Applicable

ECCN Code
EAR99

Applications
Board Mount

HTS Code
8542.39.00.01

Voltage - Supply
10V~16V

Output
0 mV ~ 40 mV (10V)

Termination Style
PC Pin

Body Length or Diameter
15.55mm

Body Breadth
5.33 mm

Output Type
Wheatstone Bridge

Response Time
1000 µs

Operating Pressure
7.25PSI (50kPa)

Pressure Type
Differential

Port Style
No Port

Linearity
0.4 %

Sensors/Transducers Type
PRESSURE SENSOR,PEIZORESISTIVE

Housing
PLASTIC

Pressure Range-Max
7.25 Psi

Accuracy-Max
0.4%

Offset-Nom
0MV

Sensitivity (mV/V)
0.8 mV/V

Body Height
13.31mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for NXP MPX2053D.

MPX2053D Overview

As a convenience, the transducer is included in package 4-SIP Module. Reliable performance is ensured by setting the transducer temperature to -40°C~125°C. With a voltage supply of 10V~16V, the transducers can function properly. This transducer can handle pressures up to 7.25 Psi.

MPX2053D Features

Moisture Sensitivity Level: Not Applicable
Package / Case: 4-SIP Module
Operating Temperature: -40°C~125°C
MPX2053 series
Sensitivity (mV/V): 0.8 mV/V
Operating Pressure: 7.25PSI (50kPa)

MPX2053D Applications

There are a lot of NXP USA Inc.
MPX2053D Transducers applications.

Indoor/Outdoor Navigation (dead-reckoning, floor/elevator/step detection)
Vertical velocity monitoring
Leisure, Sports, and Fitness Activity Identification
Weather Forecasting
Hydrogen Storage
Refrigerant pressure monitoring in HVAC/R systems
Dry air system pressure, process controls and automation
Dry air system monitoring
Hydraulic, brake, and engine oil fluid pressure monitoring
Air brake pressure monitoring
