NXP MPC8308VMAFD

Manufacturer No:

MPC8308VMAFD

Manufacturer:

NXP

Package:

MAPBGA

Description:

Microprocessor 473-Pin 333MHz MAPBGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MPC8308VMAFD information

NXP MPC8308VMAFD technical specifications, attributes, parameters and parts with similar specifications to NXP MPC8308VMAFD.

Type
Parameter

Mount
Surface Mount

Package / Case
MAPBGA

Number of Pins
473

Weight
1.623294g

JESD-609 Code
e2

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
473

ECCN Code
3A991.A.2

Terminal Finish
TIN COPPER/TIN SILVER

Max Operating Temperature
105°C

Min Operating Temperature
0°C

HTS Code
8542.31.00.01

Technology
CMOS

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Frequency
333MHz

Time@Peak Reflow Temperature-Max (s)
40

Voltage
1V

Max Supply Voltage
3.3V

Min Supply Voltage
950mV

uPs/uCs/Peripheral ICs Type
MICROPROCESSOR, RISC

Frequency (Max)
333MHz

Data Bus Width
32b

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for NXP MPC8308VMAFD.

MPC8308VMAFD Overview

This figure shows the major functional units within the MPC8308. The e300 core in the MPC8308, with its 16 Kbytes of instruction and 16 Kbytes of data cache, implements the Power Architecture user instruction set architecture and provides hardware and software debugging support. In addition, the MPC8308 offers a PCI Express controller, two three-speed 10, 100, 1000 Mbps Ethernet controllers (eTSEC), a DDR2 SDRAM memory controller, a SerDes block, an enhanced local bus controller (eLBC), an integrated programmable interrupt controller (IPIC), a general purpose DMA controller, two I2 C controllers, dual UART (DUART), GPIOs, USB, general purpose timers, and an SPI controller. The high level of integration in the MPC8308 helps simplify board design and offers significant bandwidth and performance.

MPC8308VMAFD Features

Fully Programmable 32-Bit General-Purpose Processor with 128-Megabyte Address Range

Pixel Processing?XY Addressing.and Window Checking Built into the instruction Set

Programmable 1.2.4?8.0r 16-Bit PixelSize with 16 Boolean and 6 Arithmetic pixe Processing Options (Raster-Opsl

30 General-Purpose 32bit Registers and32-bi1 Stack Pointer

256-Byte LRU On-Chip Instruction Cache

Direct Interfacing to Both Conventional DRAM and Multiport Video RAM

Dedicated 8/16-Bit Host Processor Interface and HOLD/HLDA Interface

Programmable CRT Control(HSYNCVSYNC?BLANK)

High·Level Language Support

Ful Line of Hardware and Software Development Tools Including a Compiler

68-Leaded Packaging (PLCC)

5-Volt CMOS Technology

MPC8308VMAFD Applications

Domestic and industrial drives:

Compressors

Pumps

Fans
