Manufacturer No:

MMVL109T1G

Manufacturer:

ONSEMI

Package:

SC-76, SOD-323

Description:

Single Surface Mount 32pF @ 3V 1MHz -55°C~150°C TJ Capacitance Ratio-6.5 2 Terminations SILICON DUAL SC-76, SOD-323

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MMVL109T1G information

ONSEMI MMVL109T1G technical specifications, attributes, parameters and parts with similar specifications to ONSEMI MMVL109T1G.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • SC-76, SOD-323
  • Number of Pins
  • 2
  • Diode Element Material
  • SILICON
  • Operating Temperature
  • -55°C~150°C TJ
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2006
  • JESD-609 Code
  • e3
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 2
  • Termination
  • SMD/SMT
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin (Sn)
  • Additional Feature
  • HIGH RELIABILITY
  • HTS Code
  • 8541.10.00.80
  • Capacitance
  • 26pF
  • Subcategory
  • Varactors
  • Voltage - Rated DC
  • 30V
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • Qualification Status
  • Not Qualified
  • Number of Elements
  • 1
  • Diode Type
  • Single
  • Capacitance @ Vr, F
  • 32pF @ 3V 1MHz
  • Reverse Voltage
  • 30V
  • Frequency Band
  • VERY HIGH FREQUENCY
  • Diode Capacitance-Nom
  • 29pF
  • Capacitance Ratio
  • 6.5
  • Capacitance Ratio Condition
  • C3/C25
  • Diode Cap Tolerance
  • 10.34%
  • Quality Factor-Min
  • 200
  • Q @ Vr, F
  • 200 @ 3V, 50MHz
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ONSEMI MMVL109T1G.

MMVL109T1G Overview


In some cases, the device can deliver a value of 26pF if its capacitance is insufficient.Its capacitance ratio is 6.5, meaning that it is capable of storing a charge.A 10.34% tolerance is measured on its diode cap.By passing it through, you can deliver a diode capacitance of 29pF.In order for the operating temperature to be stable, it should be no different from -55°C~150°C TJ.In addition, the SC-76, SOD-323 package can be used to save space.Electrically, this device is rated at DC voltage 30V.With this device, varying 30V reverse voltages are supported.

MMVL109T1G Features


a diode cap tolerance of 10.34%
a temperature range of -55°C~150°C TJ


MMVL109T1G Applications


There are a lot of ON Semiconductor
MMVL109T1G applications of varactors.


  • -Low voltage battery portables
  • -In car radio
  • -MP3 players
  • Voltage and Temperature Controlled Crystal Oscillators
  • Mobile Radio and Pagers.
  • Digital Radio receivers
  • Mobile radios and Pagers
  • Cellular telephones
  • Voltage controlled Crystal Oscillators
  • Voltage controlled Crystal Oscillators
