Standex MK14-1A66B-200W

Manufacturer No:

MK14-1A66B-200W

Manufacturer:

Standex

Package:

Molded Body

Description:

MK14 Series Reed Switch Wire Leads SPST-NO Magnet -30°C~70°C TA 25.5mm Height NO Molded Body

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MK14-1A66B-200W information

Standex MK14-1A66B-200W technical specifications, attributes, parameters and parts with similar specifications to Standex MK14-1A66B-200W.

Type
Parameter

Factory Lead Time
12 Weeks

Package / Case
Molded Body

Surface Mount
NO

Mounting Feature
PANEL MOUNT

Actuator Material
Magnet

Operating Temperature
-30°C~70°C TA

Series
MK14

Published
2014

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
Wire Leads

Type
Reed Switch

Voltage - Rated DC
200V

Reach Compliance Code
unknown

Current Rating
500mA

Termination Style
Wire Leads

Body Length or Diameter
4mm

Output Type
SPST-NO

Operating Supply Voltage
200V

Nominal Supply Current
1.25A

Response Time
100 ?s

Sensing Method
Magnetic

Housing
PBT FIBERGLASS REINFORCED

Must Operate
10 ~ 30AT

Body Height
25.5mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Standex MK14-1A66B-200W.

MK14-1A66B-200W Overview

A magnetic position sensor module is packaged in a Molded Body package. When operating, the magnetic position sensors modules should apply a voltage of 200V. Sensor modules typically draw 1.25A current. It is recommended that the rated voltage in the DC circuit for sensor modules be 200V.

MK14-1A66B-200W Features

Package / Case: Molded Body
MK14 Series
Operating Temperature: -30°C~70°C TA
Operating Supply Voltage: 200V
Response Time: 100 ?s

MK14-1A66B-200W Applications

There are a lot of Standex-Meder Electronics
MK14-1A66B-200W Magnetic Position Sensors Modules applications.

Clutch/brake position sensor
Lighting actuation slave sensor
Wiper home/end position sensor
End of travel and index sensors
Industrial controls
White goods
Position and limit sensing
RPM measurement
Flow metering
Commutation of brushless DC motors
