ONSEMI MJD31C1
ONSEMI MJD31C1

ONSEMI MJD31C1

Manufacturer No:

MJD31C1

Manufacturer:

ONSEMI

Package:

TO-251-3 Short Leads, IPak, TO-251AA

Description:

NPN -65°C~150°C TJ 50?A 1 Elements 3 Terminations SILICON NPN TO-251-3 Short Leads, IPak, TO-251AA Tube Through Hole

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MJD31C1 information

ONSEMI MJD31C1 technical specifications, attributes, parameters and parts with similar specifications to ONSEMI MJD31C1.

  • Type
  • Parameter
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • TO-251-3 Short Leads, IPak, TO-251AA
  • Number of Pins
  • 3
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • -65°C~150°C TJ
  • Packaging
  • Tube
  • Published
  • 2009
  • JESD-609 Code
  • e0
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin/Lead (Sn/Pb)
  • HTS Code
  • 8541.29.00.95
  • Subcategory
  • Other Transistors
  • Voltage - Rated DC
  • 100V
  • Max Power Dissipation
  • 1.56W
  • Peak Reflow Temperature (Cel)
  • 240
  • Reach Compliance Code
  • not_compliant
  • Current Rating
  • 3A
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Base Part Number
  • MJD31
  • Pin Count
  • 3
  • Number of Elements
  • 1
  • Element Configuration
  • Single
  • Case Connection
  • COLLECTOR
  • Transistor Application
  • AMPLIFIER
  • Gain Bandwidth Product
  • 3MHz
  • Polarity/Channel Type
  • NPN
  • Transistor Type
  • NPN
  • Collector Emitter Voltage (VCEO)
  • 1.2V
  • Max Collector Current
  • 3A
  • DC Current Gain (hFE) (Min) @ Ic, Vce
  • 10 @ 3A 4V
  • Current - Collector Cutoff (Max)
  • 50?A
  • Vce Saturation (Max) @ Ib, Ic
  • 1.2V @ 375mA, 3A
  • Collector Emitter Breakdown Voltage
  • 100V
  • Transition Frequency
  • 3MHz
  • Collector Emitter Saturation Voltage
  • 1.2V
  • Collector Base Voltage (VCBO)
  • 100V
  • Emitter Base Voltage (VEBO)
  • 5V
  • hFE Min
  • 25
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Contains Lead

Download datasheets and manufacturer documentation for ONSEMI MJD31C1.

Datasheets:

PCN Obsolescence/ EOL:

ReachStatement:

MJD31C1 Overview


This device has a DC current gain of 10 @ 3A 4V, which is the ratio between the base current and the collector current.This design offers maximum flexibility with a collector emitter saturation voltage of 1.2V.A VCE saturation (Max) of 1.2V @ 375mA, 3A means Ic has reached its maximum value(saturated).A high level of efficiency can be achieved if the base voltage of the emitter remains at 5V.This device has a current rating of 3A which corresponds to the maximum current it can carry for an indefinite period without deteriorating too much.As you can see, the part has a transition frequency of 3MHz.A maximum collector current of 3A volts is possible.

MJD31C1 Features


the DC current gain for this device is 10 @ 3A 4V
a collector emitter saturation voltage of 1.2V
the vce saturation(Max) is 1.2V @ 375mA, 3A
the emitter base voltage is kept at 5V
the current rating of this device is 3A
a transition frequency of 3MHz


MJD31C1 Applications


There are a lot of ON Semiconductor
MJD31C1 applications of single BJT transistors.


  • Inverter
  • Interface
  • Driver
  • Muting

User Guide
