Microchip MIC94305YMT-TR
Microchip MIC94305YMT-TR

Microchip MIC94305YMT-TR

Manufacturer No:

MIC94305YMT-TR

Manufacturer:

Microchip

Package:

6-UFDFN Exposed Pad

Description:

500mA Switch with Ripple Blocker Technology

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MIC94305YMT-TR information

Microchip MIC94305YMT-TR technical specifications, attributes, parameters and parts with similar specifications to Microchip MIC94305YMT-TR.

  • Type
  • Parameter
  • IGND Typical µA (microampere)
  • 150
  • IOUT #1 Max mA (milliampere)
  • 500
  • Load Dump
  • Noise Rms Freq Interval µV (microvolt)
  • 98
  • # of Out
  • 1
  • Driver Type
  • Single LDOs/Ripple blocker
  • Rated IOUT Max mA (milliampere)
  • 500
  • Reverse Battery
  • Reverse Current Protect
  • Soft Start Pin
  • VIN Max V (volt)
  • 3.6
  • VIN Min (V) V (volt)
  • 1.8
  • VOUT V (volt)
  • Input Follower
  • Line Regulation (%)
  • 0
  • Load Regulation(%)
  • 0

Download datasheets and manufacturer documentation for Microchip MIC94305YMT-TR.

Data Sheets:

The MIC94305 is an integrated load switch that incorporates Ripple Blocker™ active filter technology. The MIC94305 provides high-frequency ripple attenuation (switching noise rejection) for applications where switching noise cannot be tolerated by sensitive downstream circuits, such as RF applications. A low-voltage logic enable pin disconnects the pass element and puts the MIC94305 in a low current-shutdown state when disabled.

The MIC94305 operates from an input voltage of 1.8V to 3.6V, allowing true load switching of low-voltage power rails in any electronic device. The output voltage (VOUT) is set at a fixed drop (typically 170mV) from the input voltage (VOUT = VIN - 170mV). This maintains high efficiency independent of given load conditions and currents.

The MIC94305 is packaged in a 6-pin 1.6mm x 1.6mm Thin DFN package, and has a junction operating temperature range of -40°C to +125°C.



  • 1.8V to 3.6V input voltage range
  • Active noise rejection over a wide frequency band: >60dB from 40kHz to 5MHz
  • Rated to 500mA output current
  • Current-limit and thermal-limit protected
  • 1.6mm x 1.6mm, 6-pin Thin DFN
  • Logic-controlled enable pin
  • -40°C to +125°C junction temperature range

User Guide
