Microchip MIC2295YML-TR
Manufacturer No:
MIC2295YML-TR
Manufacturer:
Microchip
Package:
8-VFDFN Exposed Pad, 8-MLF®
Description:
1.2MHz 1.7A PWM Boost Converter
Quantity:
In Stock :5192
Looking for price or availability? Send us an RFQ and our sales team will respond quickly.
Shipping & Availability
Fast worldwide shipping via DHL, FedEx, UPS, and EMS.
Shipped from：HK Warehouse
Expected Shipping：Sat, May 30 - Sun, May 31, 2026
Lead Time：Inquire about availability
Date Code：Within 2 Years
Payment
We support multiple secure payment methods including PayPal, Visa, MasterCard, and American Express. All transactions are protected with advanced encryption to ensure secure and reliable payments.
Authenticity Guarantee
All components supplied by Aichiplink are sourced from trusted global suppliers and verified through strict in-house inspection and quality control procedures.
Quality Assurance
Certified in-house inspection and testing facilities ensure all components meet internationally recognized quality standards.
User Guide
Aichiplink operates certified in-house inspection and testing facilities to ensure all electronic components meet internationally recognized quality and compliance standards. Our quality management system is verified through ISO 9001 certification and industry-standard inspection procedures.
PURCHASE
Please verify all part numbers, quantities, and packaging preferences before placing your order. If substitutions are acceptable, please indicate this clearly. For time-sensitive projects, confirm estimated delivery dates and stock availability in advance. Once submitted, changes or cancellations may not be possible, especially for items marked as non-cancellable/non-returnable (NCNR). For international shipments, please ensure all import documentation is complete and accurate to avoid delays.
MEANS OF PAYMENTFor your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and Wire Transfer. Net terms may be available for qualified customers upon approval.
RFQ (REQUEST FOR QUOTATIONS)Please ensure the part numbers and quantities are accurate and complete when submitting your RFQ.
Provide target prices and acceptable alternatives, if any, to speed up the quotation process.
Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.
Step1：Prepare product
Step2：Desiccant Protection
Step3：Vacuum Packaging
Step4：Individual Package
Step5：Anti-collision Filling
Step6：Packaging Box
SHIPPING COST
1. Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.).
2. Some specific products need to reach the minimum order quantity.
3. It may cost additional remote fees for delivery if you are in a remote area.
Currently, our products are shipped through DHL, FedEx, SF, and UPS.
DELIVERY TIME1. Once the goods are shipped, estimated delivery time depends on the shipping methods you chose: FedEx International, 5-7 business days.
2. For in-stock parts, orders normally could be shipped out within 1-2days.
MIC2295YML-TR Information
Microchip MIC2295YML-TR technical specifications, attributes, parameters and parts with similar specifications to Microchip MIC2295YML-TR.
- Type
- Parameter
- Regulator Type
- Step Up (Boost)
- Switching Frequency (kHz) kHz (kilohertz)
- 1200
- Input Voltage Range Min
- 2.5
- Input Voltage Range Max
- 10
- Output Current
- 2000
- Temp Range Min
- -40
- Temp Range Max °C (degrees Celsius)
- 125
- Alternative Topology
- SEPIC, CUK, Flyback
- Vout Min (V)
- 3
- Vout Max (V)
- 34
- Type
- Parameter
- Quiescent Current (mA) typ
- 2.8
- Light Load Efficiency Mode
- No
- Switch current (A) typ
- 1.7
- Automotive Qualified
- No
- SHUTDOWN Current (µA) (Typ)
- 0.1
- Vfb V (volt)
- 1.24
- Synchronous Rectifier
- No
- Duty Cycle Max (%)
- 90
Download datasheets and manufacturer documentation for Microchip MIC2295YML-TR.
Data Sheets:
The MIC2295 is a 1.2Mhz, PWM DC/DC boost switching regulator. High power density is achieved with the MIC2295's internal 34V / 1.2A switch, allowing it to power large loads in a tiny footprint. The MIC2295 implements constant frequency 1.2MHz PWM current mode control. The MIC2295 offers internal compensation that offers excellent transient response and output regulation performance. The high frequency operation saves board space by allowing small, low-profile external components. The fixed frequency PWM scheme also reduces spurious switching noise and ripple to the input power source. The MIC2295 has an operating junction temperature range of -40°C to +125°C.
- 2.5V to 10V input voltage range
- Output voltage adjustable to 34V
- 1.2A(min) / 1.7A(typ) switch current
- 1.2MHz PWM operation
- Stable with small size ceramic capacitors
- High efficiency
- Low input and output ripple
- <1µA shutdown current
- UVLO
- Output over-voltage protection
- Over temperature shutdown
- Thin SOT23-5 package option
- -40°C to +125°C junction temperature range
