Broadcom MGA-43228-BLKG

Manufacturer No:

MGA-43228-BLKG

Manufacturer:

Broadcom

Package:

28-VFQFN Exposed Pad

Description:

38.5dB 802.16 WiMAX NARROW BAND HIGH POWER Strip 2.3GHz~2.5GHz 5V P1dB:35.5dBm 2.1dB 500mA Surface Mount

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MGA-43228-BLKG information

Broadcom MGA-43228-BLKG technical specifications, attributes, parameters and parts with similar specifications to Broadcom MGA-43228-BLKG.

Type
Parameter

Factory Lead Time
16 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
28-VFQFN Exposed Pad

Number of Pins
28

Packaging
Strip

Published
2004

JESD-609 Code
e3

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
2A (4 Weeks)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Tin (Sn)

Max Operating Temperature
150°C

Subcategory
RF/Microwave Amplifiers

Max Power Dissipation
8W

Technology
GAAS

Voltage - Supply
5V

Number of Functions
1

Construction
COMPONENT

Frequency
2.3GHz~2.5GHz

Power Supplies
5V

Number of Channels
1

Test Frequency
2.4GHz

Impedance
50Ohm

Nominal Supply Current
500mA

Power Dissipation
8W

Gain
38.5dB

RF/Microwave Device Type
NARROW BAND HIGH POWER

RF Type
802.16 WiMAX

Input Power-Max (CW)
20dBm

Noise Figure
2.1dB

P1dB
35.5dBm

Height
850?m

Length
5mm

Width
5mm

REACH SVHC
No SVHC

Radiation Hardening
No

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Broadcom MGA-43228-BLKG.

PCN Packaging:

broadcomlimited-adet5000tr1-pcnpackaging-5254.pdf

MGA-43228-BLKG Overview

An RF Amplifier with a cost-effective RF/Microwave device type of NARROW BAND HIGH POWER.A RF type of 802.16 WiMAX is provided by the RF amplifier.Using advanced packaging techniques Strip, high reliability is ensured.The RF power Amplifier has been packed in 28-VFQFN Exposed Pad for convenient overseas shipping.You should mount Amplifiers RF in the way of Surface Mount.5V voltage is available from the Amplifiers RF.If the supply current is operated in the range of 500mA or higher, it will provide its performance.On this high power RF Amplifier, there are 28 pins.1 functions are available in total for the RF Amplifier.A variety of functions can be performed on 28 terminations.Specially, RF Amplifier corresponds to type RF/Microwave Amplifiers.At150°C, RF power Amplifier shouldrun.

MGA-43228-BLKG Features

NARROW BAND HIGH POWER RF/Microwave Amplifier
RF Type 802.16 WiMAX
5V voltage
28 pins

MGA-43228-BLKG Applications

There are a lot of Broadcom Limited
MGA-43228-BLKG RF Amplifiers applications.

GPS
GLONASS
BeiDou
Galileo
Wireless communications
ISM applications
Wireless infrastructure
Automated test equipment
RF/IF gain control
Microwave Radios
