Microchip MCP79511T-I/MS
Microchip MCP79511T-I/MSMicrochip MCP79511T-I/MS

Microchip MCP79511T-I/MS

Manufacturer No:

MCP79511T-I/MS

Manufacturer:

Microchip

Package:

10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Description:

SPI GPP RTCC w/1k EEPROM, 64B SRAM and EUI-48

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MCP79511T-I/MS information

Microchip MCP79511T-I/MS technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP79511T-I/MS.

  • Type
  • Parameter
  • EEPROM Data Memory Bytes
  • 1
  • Unique ID with MAC Address
  • EUI-48
  • User SRAM (Bytes)
  • 64
  • Max Interface Speed
  • 10 MHz
  • Minimum Clock Count
  • 0.01 sec
  • Pin Count
  • 10
  • Unique ID (Bits)
  • 128
  • Temp Range Min (°C (degrees Celsius))
  • -40
  • Temp Range Max (°C (degrees Celsius))
  • 85

Download datasheets and manufacturer documentation for Microchip MCP79511T-I/MS.

Application Notes:

Data Sheets:

Errata:

The MCP79511 SPI RTCC is highly integrated with memory and advanced features normally found in higher priced devices. By starting with a basic real-time clock, digital trimming was added for higher accuracy, a battery switchover for backup power, a timestamp to log power failures and three types of memory, which includes SRAM, EEPROM and a unique ID in a locked section of EEPROM. This ID is preprogrammed with a 48-bit MAC Address, but it can also be ordered blank for the end user to program.

  • VCC Min = 1.8V
  • Icc < 5 µA Typical Standby Current
  • VBAT Min = 1.3V
  • Ibat < 700nA Typical Timekeeping & SRAM Retention Current
  • VCC to VBAT (VCC Lost)
  • VBAT to VCC (VCC Restored)
  • IRQ (VCC or VBAT)
  • Clock Out frequencies: 32.768, 8.192 & 4.096 KHz and 1 Hz
  • Adjusts up to 22 seconds/day
  • Protect: None, 1/4, 1/2 or all of array
  • Factory standard MAC address programming or custom ID available

User Guide
