Microchip MCP3909-I/SS
Microchip MCP3909-I/SS

Microchip MCP3909-I/SS

Manufacturer No:

MCP3909-I/SS

Manufacturer:

Microchip

Package:

24-SSOP (0.209, 5.30mm Width)

Description:

The MCP3909 is an energy measurement IC with active power output and ADC data output for energy metering.

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MCP3909-I/SS information

Microchip MCP3909-I/SS technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP3909-I/SS.

  • Type
  • Parameter
  • Resolution
  • 16
  • Sample Rate kSPS Max
  • 14
  • Input Channels Differential
  • 2
  • SNRtyp
  • 0
  • SFDR typ
  • 0
  • ENOB
  • 13.2
  • INL Typ LSB
  • 0

Download datasheets and manufacturer documentation for Microchip MCP3909-I/SS.

User Guide:

Application Notes:

Brochures:

Data Sheets:

The MCP3909 is an energy measurement IC supporting the IEC 62053 international energy metering specification. The output of the device includes a frequency proportional to the average active (real) power at the inputs as well as a simultaneous serial SPI interface to access the ADC channels and multiplier output data. The MCP3909 supports a dynamic range of 1000:1 and incorporates two 16-bit delta-sigma ADCs with a programmable gain up to 16. The output waveform data is available at up to 14 kHz with 16-bit ADC output and 20-bit multiplier output data. The integrated on-chip voltage reference has an ultra-low temperature drift of 15 ppm/°C.


We welcome questions, comments and recommendations for improvements to this page - please contact us at: ADCwebrequests@microchip.com if you have any; please mention the part number in the email subject header.



  • Supplies active (real) power measurement for single-phase, residential energy metering
  • Supports IEC 62053 International Energy Metering Specification and legacy IEC 1036/61036/687 Specifications
  • Two multi-bit, DAC, second-order, 16-bit, Delta-Sigma Analog-to-Digital Converters (ADCs)
  • Ultra-low drift on-chip reference: 15 ppm/°C (typ.)
  • Low IDD of 4 mA (typ.)
  • Active power pulse output
  • SPI™ interface for access to raw ADC and multiplier data
  • AEC-Q100 Grade 1
