Microchip MCP2557FDT-H/SN
Manufacturer No:
MCP2557FDT-H/SN
Manufacturer:
Package:
8-SOIC (0.154, 3.90mm Width)
Description:
CAN Flexible Data Rate Transceiver w/Silent Mode
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
MCP2557FDT-H/SN information
Microchip MCP2557FDT-H/SN technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP2557FDT-H/SN.
- Type
- Parameter
- CAN FD
- Yes
- Bitrate Max [MBits/s]
- 8
- Operating Temperature Max. (C)
- 150
- Operating Temperature Min. (C)
- -40
- Operating Voltage Max. (V)
- 5.5
- Operating Voltage Min. (V)
- 4.5
Download datasheets and manufacturer documentation for Microchip MCP2557FDT-H/SN.
Data Sheets:
- Supports both Classic CAN or CAN Flexible Data Rate applications
- Optimized for CAN FD (Flexible Data rate) at 2, 5 and 8 Mbps Operation
- Meets the latest ISO/DIS 11898-2:2015 specification
- Prevent disruption on the network due to local fault
- Increased system reliability through redundancy
- Test connection of the network
- AEC-Q100 Grade 0
- VIO Supply Pin to Interface Directly to CAN Controllers and Microcontrollers with 1.7V to 5.5V I/O
- CAN Bus Pins are Disconnected when Device is Unpowered
- An Unpowered Node or Brown-Out Event will Not Load the CAN Bus
- Permanent Dominant Detection on TXD
- Permanent Dominant Detection on Bus
- Power-on Reset and Voltage Brown-Out Protection on VDD Pin
- Protection Against Damage Due to Short-Circuit Conditions (Positive or Negative Battery Voltage)
- Protection Against High-Voltage Transients in Automotive Environments
- Automatic Thermal Shutdown Protection
- Suitable for 12V and 24V Systems
- Extremely robust meeting automotive EMC hardware requirements
- Smallest 8L CAN transceiver package available-2x3 TDFN-8L
- Also available in SOIC-8L and 3x3 DFN-8L
- High (H): -40°C to +150°C
User Guide
