Microchip MCP1790T-3302E/EBVAO

Manufacturer No:

MCP1790T-3302E/EBVAO

Manufacturer:

Microchip

Package:

TO-263-4, D2Pak (3 Leads + Tab), TO-263AA

Description:

Enable Fixed 2.54mm MCP1790 PMIC Automotive, AEC-Q100 Series TO-263-4, D2Pak (3 Leads + Tab), TO-263AA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MCP1790T-3302E/EBVAO information

Microchip MCP1790T-3302E/EBVAO technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP1790T-3302E/EBVAO.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
TO-263-4, D2Pak (3 Leads + Tab), TO-263AA

Surface Mount
YES

Operating Temperature
-40°C~125°C

Packaging
Tape & Reel (TR)

Series
Automotive, AEC-Q100

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
3

Terminal Position
SINGLE

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
NOT SPECIFIED

Number of Functions
1

Terminal Pitch
2.54mm

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Base Part Number
MCP1790

JESD-30 Code
R-PSSO-G3

Current - Supply (Max)
210μA

Voltage - Input (Max)
30V

Output Type
Fixed

Output Configuration
Positive

Current - Output
70mA

Control Features
Enable

Output Voltage 1
3.3V

Voltage - Output (Min/Fixed)
3.3V

Number of Regulators
1

Protection Features
Over Current, Over Temperature, Short Circuit

Current - Quiescent (Iq)
130μA

Voltage Dropout (Max)
1.3V @ 70mA

PSRR
90dB ~ 80dB (100Hz ~ 1kHz)

Output Voltage1-Max
3.3825V

Height Seated (Max)
5.08mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Microchip MCP1790T-3302E/EBVAO.

MCP1790T-3302E/EBVAO Overview

Tape & Reel (TR) cases are used for delivery. The Liner regulator IC is packaged in TO-263-4, D2Pak (3 Leads + Tab), TO-263AA case. On the Linear IC itself, there are 3 terminations. Fixed is the output type of the Voltage Regulator IC. As part of this electrical component, 1 regulators are implemented. Variations are made to the Surface Mount operating temperature range by the Voltage Regulator IC. Default settings are set to -40°C~125°C degrees. There is a Positive configured as the output function for this IC regulator. There is a current output of 70mA from this regulator IC. For your information, the basic part number for this regulator IC is MCP1790. This IC regulator is a part of the Automotive, AEC-Q100 Series of devices.
