Microchip MCP1640B-I/MC
Manufacturer No:
MCP1640B-I/MC
Manufacturer:
Microchip
Package:
8-VFDFN Exposed Pad
Description:
PFM/PWM Enabled, True Output Disconnect
Quantity:
In Stock :4102
Looking for price or availability? Send us an RFQ and our sales team will respond quickly.
Shipping & Availability
Fast worldwide shipping via DHL, FedEx, UPS, and EMS.
Shipped from：HK Warehouse
Expected Shipping：Mon, Jun 1 - Tue, Jun 2, 2026
Lead Time：Inquire about availability
Date Code：Within 2 Years
Payment
We support multiple secure payment methods including PayPal, Visa, MasterCard, and American Express. All transactions are protected with advanced encryption to ensure secure and reliable payments.
Authenticity Guarantee
All components supplied by Aichiplink are sourced from trusted global suppliers and verified through strict in-house inspection and quality control procedures.
Quality Assurance
Certified in-house inspection and testing facilities ensure all components meet internationally recognized quality standards.
User Guide
Aichiplink operates certified in-house inspection and testing facilities to ensure all electronic components meet internationally recognized quality and compliance standards. Our quality management system is verified through ISO 9001 certification and industry-standard inspection procedures.
PURCHASE
Please verify all part numbers, quantities, and packaging preferences before placing your order. If substitutions are acceptable, please indicate this clearly. For time-sensitive projects, confirm estimated delivery dates and stock availability in advance. Once submitted, changes or cancellations may not be possible, especially for items marked as non-cancellable/non-returnable (NCNR). For international shipments, please ensure all import documentation is complete and accurate to avoid delays.
MEANS OF PAYMENTFor your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and Wire Transfer. Net terms may be available for qualified customers upon approval.
RFQ (REQUEST FOR QUOTATIONS)Please ensure the part numbers and quantities are accurate and complete when submitting your RFQ.
Provide target prices and acceptable alternatives, if any, to speed up the quotation process.
Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.
Step1：Prepare product
Step2：Desiccant Protection
Step3：Vacuum Packaging
Step4：Individual Package
Step5：Anti-collision Filling
Step6：Packaging Box
SHIPPING COST
1. Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.).
2. Some specific products need to reach the minimum order quantity.
3. It may cost additional remote fees for delivery if you are in a remote area.
Currently, our products are shipped through DHL, FedEx, SF, and UPS.
DELIVERY TIME1. Once the goods are shipped, estimated delivery time depends on the shipping methods you chose: FedEx International, 5-7 business days.
2. For in-stock parts, orders normally could be shipped out within 1-2days.
MCP1640B-I/MC Information
Microchip MCP1640B-I/MC technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP1640B-I/MC.
- Type
- Parameter
- Max Duty Cycle (%)
- 90
- Input Voltage Range Max
- 5.5
- Input Voltage Range Min
- 0.65
- # of Outputs
- 1
- Output Current
- 1000
- Driver Type
- Boost
- Quiescent Current
- 0.019
- Synchronous Rectifier
- Yes
- Temp Range Max °C (degrees Celsius)
- 85
- Temp Range Min
- -40
- Type
- Parameter
- Vout Max
- 5.5
- Vfb V (volt)
- 1.21
- VoutMin
- 2
- Vref (V)
- 0
Download datasheets and manufacturer documentation for Microchip MCP1640B-I/MC.
Brochures:
Data Sheets:
User Guide:
Application Notes:
The MCP1640/40B/40C/40D is a compact, high-efficiency, fixed frequency, synchronous step-up DC-DC converter. It provides an easy-to-use power supply solution for applications powered by either one-cell, two-cell, or three-cell alkaline, NiCd, NiMH, one-cell Li-Ion or Li-Polymer batteries. The MCP1640/40B/40C/40D provides very high efficiency through integration of the low resistance N-Channel Boost switch and synchronous P-Channel switch.
- Up to 96% Typical Efficiency
- IOUT > 100 mA @ 1.2V VIN, 3.3V VOUT
- IOUT > 350 mA @ 2.4V VIN, 3.3V VOUT
- IOUT > 350 mA @ 3.3V VIN, 5.0V VOUT
- Low Start-up Voltage: 0.65V
- Operating Input Voltage: 0.35V
- Adjustable Output Voltage Range: 2.0V to 5.5V
- Maximum Input Voltage < VOUT < 5.5V
- Automatic PFM/PWM Operation
- PWM Operation at 500 kHz
- Low Device Quiescent Current: 19 µA – typical PFM Mode
- Shutdown Current (All States): < 1 µA
- Internal Synchronous Rectifier
- Internal Compensation
- Inrush Current Limiting and Internal Soft-Start
- True Load Disconnect Shutdown
- Low Noise, Anti-Ringing Control
- Over-temperature Protection
- SOT23-6 or 2x3 8-Lead DFN packages
