Microchip MCP1501T-40E/CHY

Manufacturer No:

MCP1501T-40E/CHY

Manufacturer:

Microchip

Package:

SOT-23-6

Description:

0.10% precision buffered voltage reference

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MCP1501T-40E/CHY information

Microchip MCP1501T-40E/CHY technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP1501T-40E/CHY.

Type
Parameter

Max Load Current (mA)
20

Initial Accuracy (max%)
0.1

Vcc Range Min (V)
1.65

Vcc Range Max (V)
5.5

VIN Max V (volt)
5.5

VOUT V (volt)
1.024V, 1.250V, 1.800V, 2.048V, 2.500V, 3.000V, 3.300V, 4.096V, 4.500V, 5.000V

Output Current Min
-20mA

Output Current Max
20mA

Noise Rms Freq Interval
30

Temperature Coefficient (ppm/°C)
50

Download datasheets and manufacturer documentation for Microchip MCP1501T-40E/CHY.

Data Sheets:

3eb3d34fe705673be6939a3e90374af7.pdf

The MCP1501 is a high-precision buffered voltage reference with an initial accuracy of 0.10% and is available in 10 voltage options. The MCP1501 is a low-drift bandgap-based reference and uses chopper-based amplifiers which significantly reduces the drift and provides high current output. The MCP1501 is available in a very small 2x2 WDFN package, as well as the SOT-23 and SOIC packages. SOT-23 package is AEC-Q100 automotive qualified.

Maximum Temperature Coefficient: 50 ppm/°C from -40°C to +125°C

Initial Accuracy: 0.10%

Operating Temperature Range: -40 to +125°C

Line Regulation: 50 ppm/V maximum

Load Regulation: 40 ppm/mA maximum

Low Typical Operating Current: 140 µA

Output Noise (.1 Hz to 10 kHz): 30 µVRMS

Packages: 8L 2x2 WDFN, 6L SOT-23, 8L SOIC

AEC-Q100 qualified, Grade 1 (Only SOT-23 package is automotive qualified)

1.024V
1.250V
1.800V
2.048V
2.500V
3.000V
3.300V
4.096V
4.500V
5.000V
