MCP14628-E/MF Information

Microchip MCP14628-E/MF technical specifications, attributes, parameters and parts with similar specifications to Microchip MCP14628-E/MF.

  • Type
  • Parameter
  • Capacitive Load Drive
  • 3300 pF in 10 ns
  • MOSFET Driver Type
  • Synchronous
  • Maximum Supply Voltage V (volt)
  • 5.5
  • Peak Sink Current A (ampere)
  • 2
  • Peak Source Current A (ampere)
  • 2
  • Propagation Delay tD1 ns (nanosecond)
  • 15
  • Propagation Delay tD2 ns (nanosecond)
  • 22
  • Sink Resistance Ω (ohm)
  • 1
  • Source Resistance Ω (ohm)
  • 1
  • Fall Time tF ns (nanosecond)
  • 10
  • Type
  • Parameter
  • Rise Time tR ns (nanosecond)
  • 10

Download datasheets and manufacturer documentation for Microchip MCP14628-E/MF.

Application Notes:

Brochures:

Data Sheets:

The MCP14628 is a synchronous MOSFET gate driver used for driving MOSFETs in a rectified bridge arrangement. This type of arrangement is typical of synchronous buck converter topologies. There are two separate drivers contained in the MCP14628. The low-side gate driver output drives a non-floating or ground reference N-Channel MOSFET. The high-side driver is designed to drive a floating N-Channel MOSFET. since the N-Channel is floating, this output needs to be able to handle the high voltages required to fully turn on the high-side MOSFET. An external bootstrap capacitor is used to provide the additional voltage. The MCP14628 is available in a surface mount 8 Lead SOIC package with a body width of 150 mils and the 8 Lead 3 x 3 mm DFN package.



  • Adaptive Cross conduction protection
  • High capacitive load drive Capability: 3000 pF in 8.0 ns (typical)
  • Low Supply Current: 80 µA (typical)
  • High Peak Output Current: Source 2 A (UGATE & LGATE) Sink 2 A (UGATE) & 4 A (LGATE)
  • Internal Bootstrap Blocking Device
  • Enhanced Light Load Efficiency Mode
  • Supports Floating High-Side Drive
  • Packaging: 8 Lead surface mount SOIC, 150 mil body 8 Lead 3mmX3mm DFN
