IXYS MCC312-16IO1
IXYS MCC312-16IO1

IXYS MCC312-16IO1

Manufacturer No:

MCC312-16IO1

Manufacturer:

IXYS

Package:

Y1-CU

Description:

SCR DUAL 1600V 520A Y1-CU

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MCC312-16IO1 information

IXYS MCC312-16IO1 technical specifications, attributes, parameters and parts with similar specifications to IXYS MCC312-16IO1.

  • Type
  • Parameter
  • Factory Lead Time
  • 28 Weeks
  • Mount
  • Chassis Mount, Panel, Screw
  • Mounting Type
  • Chassis Mount
  • Package / Case
  • Y1-CU
  • Number of Pins
  • 7
  • Number of Elements
  • 2
  • Number of SCRs/Diodes
  • 2 SCRs
  • Operating Temperature
  • -40°C~140°C TJ
  • Packaging
  • Bulk
  • Published
  • 2002
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • Not Applicable
  • Number of Terminations
  • 7
  • Additional Feature
  • UL RECOGNIZED
  • HTS Code
  • 8541.30.00.80
  • Voltage - Rated DC
  • 1.6kV
  • Terminal Position
  • UPPER
  • Terminal Form
  • UNSPECIFIED
  • Current Rating
  • 1.04kA
  • Base Part Number
  • MC*312
  • Configuration
  • SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
  • Case Connection
  • ISOLATED
  • Max Repetitive Reverse Voltage (Vrrm)
  • 1.6kV
  • Reverse Voltage
  • 1.6kV
  • Hold Current
  • 150mA
  • Trigger Device Type
  • SCR
  • Voltage - Gate Trigger (Vgt) (Max)
  • 2V
  • Current - Non Rep. Surge 50, 60Hz (Itsm)
  • 9200A 10100A
  • On-State Current-Max
  • 320000A
  • Structure
  • Series Connection - All SCRs
  • Repetitive Peak Off-state Voltage
  • 1600V
  • Leakage Current (Max)
  • 40mA
  • Current - On State (It (AV)) (Max)
  • 320A
  • Non-Repetitive Pk On-state Cur
  • 9800 A
  • Desc. of Screw Terminals
  • A-K-AK
  • Desc. of Quick-Connects
  • 2G-2GR
  • Height
  • 49mm
  • Length
  • 115mm
  • Width
  • 50mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for IXYS MCC312-16IO1.

Datasheets:

Other Related Documents:

The IXYS MCC312-16IO1 is a dual SCR (silicon-controlled rectifier) module designed for high-power applications. It features two 1600V SCRs with a 520A current rating, and a Y1-CU construction. This module is ideal for applications that require high-power switching, such as motor control, power supplies, and power conversion.

Features of the IXYS MCC312-16IO1 include:

• Dual 1600V SCRs with 520A current rating
• Y1-CU construction
• High-power switching capability
• Low on-state voltage drop
• High surge current capability
• Low thermal resistance
• High temperature operation

Applications of the IXYS MCC312-16IO1 include:

• Motor control
• Power supplies
• Power conversion
• Uninterruptible power supplies
• High-power switching
• High-voltage switching
• High-current switching
