NXP MC7447AHX1167NB
NXP MC7447AHX1167NB

NXP MC7447AHX1167NB

Manufacturer No:

MC7447AHX1167NB

Manufacturer:

NXP

Package:

360-BCBGA, FCCBGA

Description:

1.27mm PowerPC G4 32-bit Microprocessor MPC74xx Series MC7447 1.3V 360-BCBGA, FCCBGA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MC7447AHX1167NB information

NXP MC7447AHX1167NB technical specifications, attributes, parameters and parts with similar specifications to NXP MC7447AHX1167NB.

  • Type
  • Parameter
  • Factory Lead Time
  • 12 Weeks
  • Package / Case
  • 360-BCBGA, FCCBGA
  • Surface Mount
  • YES
  • Operating Temperature
  • 0°C~105°C TA
  • Packaging
  • Tray
  • Series
  • MPC74xx
  • Published
  • 1994
  • JESD-609 Code
  • e0
  • Part Status
  • Not For New Designs
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 360
  • ECCN Code
  • 3A991.A.1
  • Terminal Finish
  • Tin/Lead (Sn/Pb)
  • Additional Feature
  • ALSO REQUIRES 1.8V OR 2.5V SUPPLY
  • HTS Code
  • 8542.31.00.01
  • Technology
  • CMOS
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BALL
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 1.3V
  • Terminal Pitch
  • 1.27mm
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • Base Part Number
  • MC7447
  • JESD-30 Code
  • S-CBGA-B360
  • Supply Voltage-Min (Vsup)
  • 1.25V
  • Speed
  • 1.167GHZ
  • uPs/uCs/Peripheral ICs Type
  • MICROPROCESSOR, RISC
  • Core Processor
  • PowerPC G4
  • Clock Frequency
  • 167MHz
  • Bit Size
  • 32
  • Address Bus Width
  • 36
  • Boundary Scan
  • YES
  • Low Power Mode
  • YES
  • External Data Bus Width
  • 64
  • Format
  • FLOATING POINT
  • Integrated Cache
  • YES
  • Voltage - I/O
  • 1.8V 2.5V
  • Number of Cores/Bus Width
  • 1 Core 32-Bit
  • Graphics Acceleration
  • No
  • Co-Processors/DSP
  • Multimedia; SIMD
  • Length
  • 25mm
  • Height Seated (Max)
  • 3.24mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NXP MC7447AHX1167NB.

Datasheets:

Environmental Information:

MC7447AHX1167NB Description


The MC7447AHX1167NB processor is a high-performance, low-power, 32-bit implementation of the RISC architecture. Key architectural features include 512 KB of on-chip L2 cache, a 64-bit bus interface, and a full 128-bit implementation of Our AltiVec?? technology. MC7447AHX1167NB processor is ideal for leading-edge computing, embedded network control, and signal processing applications.

Designed as pin-compatible replacements for Our MPC7447 products, the MC7447AHX1167NB has been shown to reach speeds of 1.5 GHz. MC7447AHX1167NB processor benefits from Our silicon-on-insulator (SOI) process technology, engineered to help deliver significant power savings without sacrificing speed. Low-power versions of the MC7447AHX1167NB are available.



MC7447AHX1167NB Features


Four integer units (three simple plus one complex)

Double-precision floating point unit

Four AltiVec? technology units (simple, complex, floating, and permute)

Load/store unit

Branch processing unit

The clock frequency can be changed dynamically

Temperature sensing diodes included monitoring die temperature



MC7447AHX1167NB Applications


Automotive

Infotainment & cluster

Communications equipment

Wireless infrastructure

Industrial

Medical
