NXP MC68LC060RC66
NXP MC68LC060RC66

NXP MC68LC060RC66

Manufacturer No:

MC68LC060RC66

Manufacturer:

NXP

Package:

206-BPGA

Description:

68060 Microprocessor M680x0 Series MC68LC060 206-BPGA

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

MC68LC060RC66 information

NXP MC68LC060RC66 technical specifications, attributes, parameters and parts with similar specifications to NXP MC68LC060RC66.

  • Type
  • Parameter
  • Package / Case
  • 206-BPGA
  • Supplier Device Package
  • 206-PGA (47.25x47.25)
  • Operating Temperature
  • 0°C~70°C TA
  • Packaging
  • Tray
  • Series
  • M680x0
  • Published
  • 1995
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Base Part Number
  • MC68LC060
  • Speed
  • 66MHz
  • Core Processor
  • 68060
  • Voltage - I/O
  • 5.0V
  • Number of Cores/Bus Width
  • 1 Core 32-Bit
  • Graphics Acceleration
  • No
  • Additional Interfaces
  • SCI, SPI
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for NXP MC68LC060RC66.

Datasheets:

MC68LC060RC66 Description


The superscalar MC68LC060RC66 represents a new line of NXP? Semiconductors microprocessor products. The MC68LC060RC66 offers superscalar integer performance of over 110 MIPS at 75 MHz. The MC68LC060RC66 is fully equipped with a floating-point unit (FPU) and a memory management unit (MMU) for high-performance embedded control applications. For cost-sensitive embedded control and desktop applications where an MMU is required, but the additional cost of an FPU is not justified, the MC68LC060RC66 offers high performance at a low cost. Designed explicitly for low-cost embedded control applications, the MC68LC060RC66 eliminates both the FPU and MMU, permitting designers to leverage MC68LC060RC66 performance while avoiding the cost of unnecessary features.



MC68LC060RC66 Features


  • Independent Instruction and Data Memory Management Units (MMUs)

  • 32-Bit Logical Address Translation to 32-Bit Physical Address

  • User-Defined 2-Bit Physical Address Extension

  • Addresses Translated in Parallel with Indexing into Data or Instruction Cache

  • 64-Entry Four-Way Set-Associative Address Translation Cache (ATC) for Each MMU (128 Total Entries)

  • Global Bit Allowing Flushes of All Nonglobal Entries from ATCs

  • Selectable 4- or 8-Kbyte Page Size



MC68LC060RC66 Applications


  • Body electronics & lighting

  • Hybrid, electric & powertrain systems

  • Infotainment & cluster

  • Broadband fixed line access

  • Datacom module

  • Wired networking

  • Wireless infrastructure
